Contact for Pricing
Overview
- Description: DIN rail 35 mm for terminal boxes.
- Material: Galvanized steel.
- Pack quantity: 5 pieces.
- Designed for mounting electrical components in control panels
- Compatible with standard DIN rail accessories
Specifications
Application | Controls and Drives; Factory Automation and Process Control |
Color | Unpainted |
Consist of | Din Rail; Mounting Components and Instruction Manual |
Construction | 18 gauge |
Depth | 35 mm |
Depth | 1.38 in |
Enclosure Material | Mild Steel |
Finish | Galvanized |
Height | 500 mm |
Height | 19.17 in |
Height | 19.69 in |
Insulation | No |
Knockouts | No |
Material | Mild Steel, Galvanized |
Material | Mild Steel |
Mounting Type | DIN Rail Mounting |
Mounting Type | DIN Rail |
Package Quantity | 5 |
Product Family | Terminal Boxes |
Series | BDR |
Size | 487x8x35mm |
Size | 19.17 x 0.3 x 1.38 inch |
Thickness | 1 mm |
Thickness | 18 ga |
Type | Mounting |
Type | IEC Enclosure Accessories |
Weight | 0.8 kg |
Weight | 1.83 lb |
Width | 8 mm |
Width | 0.3 in |
Works With | IEC |
Package Dimensions (L x W x H) | 20.31 IN x 20.06 IN x 1.22 IN |
Package Dimensions (L x W x H) | 51.5874 cm x 50.9524 cm x 3.0988 cm |
Package Weight (Imperial) | 1.830 L |
Package Weight (Metric) | 0.830 kg |
