Contact for Pricing
Overview
- Description: To replace the standard door, provides a clear view of the components installed inside the enclosure. The lock(s) are interchangeable with all nVent HOFFMAN's standard lock(s)
- Material: 1.5 mm AISI 304 stainless steel, 2 mm for enclosures with a height or width of 600 mm or greater and 4 mm clear safety glass
- Finish: 400 pre-grained stainless steel
- Protection: Complies with IP55, TYPE 12, 13, IK 07.
- Pack quantity: 1 door
- The glazed door allows the electrical components to be seen while the enclosure's door is closed
- The user can monitor the status of the components without the need for opening the enclosure's door maintaining the ingress protection
- The user can monitor the status of the components without the need for opening the enclosure's door maintaining the ingress protection
- Note: * 3 point espagnolette locking. Not suitable for AFS
Specifications
Enclosure Material | Mild Steel |
Finish | Brushed |
Height | 44 IN |
Height | 15.75 in |
IP Rating | IP55 |
Latch Quantity | 1 |
Material | AISI 304 Stainless Steel |
Material | Stainless Steel 304 |
Mounting Type | Wall-mounted |
Mounting Type | Pre-drilled mounting holes |
Nema Rating | Type 12/13 |
Nema Rating | Type 12, 13 |
Product Family | Wall Mounted |
Protection Rating | IP55 |
Series | ADCS |
Series | nVent ADCS |
Series | nVent ADCS Series |
Size | 400x600 mm |
Thickness | 0.06 IN |
Thickness | 51.40mm (2.024") |
Type | Doors |
Width | 600 mm |
Width | 23.62 in |
Window Size | 10.2 x 17.44 in |
Window Size | 343 x 366 mm |
Works With | IEC |
Package Dimensions (L x W x H) | 24 IN x 16.12 IN x 24.25 IN |
Package Dimensions (L x W x H) | 60.96 cm x 40.9448 cm x 61.595 cm |
Package Weight (Imperial) | 11.800 L |
Package Weight (Metric) | 5.353 kg |
9T18Y4322G77
Dry Type Transformers. Accessories and Lugs. Single-Phase and Three-Phase. Rainshield Kit. Frame Size: FC77, yF175.
BST
This is a screwless electrical box mount for supporting an electrical box with drywall. It is made of pre-galvanized steel and has a stamped construction. The design is one-piece break-away and is intended to prevent box pullout. Listed dimensions include a trade size of 5.25 x 3.50 x 0.023 and leg length of 2.50 in with a leg width of 0.50 in.
6011DW-25
Adjustable bar hanger. Depth 1-3/16 inch. For 3/8 inch, 1/2 inch and 5/8 inch wall board and plaster. Score marks for drywall and plaster depths. Maximum load capacity: 50 pounds (22.7 kilograms). Length: 10-1/2 inches to 18-1/2 inches. Packaged complete with fastener.
ADPS10010R-316
The nVent ADPS10010R-316 is a high-performance power distribution system designed for industrial applications requiring robust electrical connectivity and safety. Engineered with precision and durability, this system ensures reliable power distribution in demanding environments. Its advanced design supports efficient energy management, reducing downtime and operational costs. Ideal for manufacturing plants, data centers, and other industrial facilities, the ADPS10010R-316 meets stringent safety standards and offers seamless integration with existing infrastructure. Trust nVent for superior quality and performance in power distribution solutions.Frequently Asked Questions
What material is the ADCS04060 glazed door made of?
The glazed door is made of 1.5 mm AISI 304 stainless steel with a 4 mm clear safety glass.
What are the dimensions of the ADCS04060 glazed door?
The door has a height of 15.75 inches and a width of 23.62 inches.
What is the window size of the ADCS04060 glazed door?
The window size is 10.2 x 17.44 inches.
Can electrical components be viewed with the ADCS04060 door closed?
Yes, the glazed door allows electrical components to be viewed while closed, maintaining ingress protection.
What protection ratings does the ADCS04060 glazed door comply with?
It complies with IP55, TYPE 12, 13, and IK 07 ratings.
What type of lock does the ADCS04060 glazed door use?
The door features a double bit lock and 3 point espagnolette locking.
What is the finish of the ADCS04060 glazed door?
The door has a brushed stainless steel finish.
What is the thickness of the ADCS04060 glazed door material?
The stainless steel material thickness is 0.06 inches.
Is the ADCS04060 door suitable for AFS?
No, the 3 point espagnolette locking is not suitable for AFS.
