Contact for Pricing
Overview
- Used when converting a standard Free-Stand Enclosure to a Seismic Free-Stand Enclosure
- Rack Panel allows rack-mount equipment to be installed in 36-inch wide enclosures
- Seismic Rack Panel has EIA 310 specified square-holes (.375x.375) and larger openings to allow cables to pass through panel
- Use with Seismic Panel Support Kits (included) and Seismic Mounting Plate Kits to obtain Seismic standards
- Available with or without vertical cable management for copper and fiber networking cables
- Kit includes one Seismic Rack Panel and two Seismic Panel Supports with hardware
Specifications
Accessory Type | Mounting Accessories |
Application | Datacom and Telecom Equipment;Networking, Storage and Data Center |
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment |
Color | Light Gray |
Color | Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Enclosure | 1834 x 918 mm |
Fits Enclosure | 72 x 36 in |
Fits Enclosure Size | 72 x 36 in |
Fits Enclosure Size | 24.00 x 20.00 in |
Material | Steel |
Material | Mild Steel |
Mounting Type | Seismic Panel Support Kits |
Rack Units | 32 |
Series | nVent Seismic Rack Panel Kit |
Size | 72.00x36.00 inches (1834 x 918 mm) |
Thickness | 2.66 mm |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | Networking Accessories |
Weight | 130 lb |
Package Dimensions (L x W x H) | 73.2 IN x 37 IN x 37 IN |
Package Dimensions (L x W x H) | 185.928 cm x 93.98 cm x 93.98 cm |
Package Weight (Imperial) | 130.000 L |
Package Weight (Metric) | 58.968 kg |
