Contact for Pricing
Overview
- Seams continuously welded and ground smooth; no holes or knockouts
- Two-door enclosures provided with a removable centerpost for easy panel installation
- Heavy-duty lifting eyes are Type 316L stainless steel
- Heavy-duty three-point latching mechanism operated by Type 316L stainless steel PowerGlide padlocking handle
- Seemless foam-in-place gasket assures a water-tight and dust-tight seal
- Body flange trough collar excludes liquids and contaminants
- Heavy-gauge continuous hinges support each door
- High-impact thermoplastic data pocket provided with each enclosure
- Mounting channels welded horizontally to interior body sides at top, bottom and center
- Optional panels and rack mounting angles can be mounted anywhere along channels
Specifications
Application | Controls and Drives;Corrosive Environments;Hygienic Environments |
Color | Unpainted |
Color | Brushed |
Depth | 459 mm |
Depth | 18.06 |
Depth | 459 |
Finish | Brushed #3 |
Height | 60.06 |
Height | 1,526 |
Height | 1,526 mm |
Ip Rating | IP66/IP67 |
IP Rating | IP66 |
Material | SS304 |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Freestanding |
Mounting Type | Freestand |
NEMA Rating | 4X Watertight, corrosion-resistant |
NEMA Rating | 4X |
Nema Rating | Type 4X |
Protection Rating | NEMA Type 4X |
Series | Freestand 2 Door Single Access 3Pt |
Size | 60.06x48.06x18.06 in |
Size | 60x48x18 |
Size | 60x48x18 inches |
Thickness | 2.78 mm |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | Stainless Steel Freestanding Industrial Enclosures |
Type Number | Type 3R |
Weight | 368 lb |
Width | 48.06 |
Width | 1,221 |
Width | 1,221 mm |
Package Dimensions (L x W x H) | 67 IN x 53.5 IN x 24 IN |
Package Dimensions (L x W x H) | 170.18 cm x 135.89 cm x 60.96 cm |
Package Weight (Imperial) | 368.000 L |
Package Weight (Metric) | 166.925 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the A604818SSFSDN4 Enclosure
Step-by-step guide for installing the A604818SSFSDN4 enclosure, including mounting, wiring, and initial setup.
Estimated time: 1h
Tools needed:
Screwdriver, Hole saw, Punch tool
Supplies needed:
Watertight conduit hubs, Lockwashers, Mounting screws
- Prepare the enclosure
Install the external toothed lockwasher under one of the nuts securing the panel to ensure proper bonding between the panel and the enclosure.
- Cut conduit openings
Use a hole saw or Greenlee-type punch to cut the required holes for conduit entry in the top, bottom, or side walls of the enclosure, following the size specifications in the provided table.
- Install conduit hubs
Install the approved watertight conduit hubs into the openings according to the manufacturer's instructions, ensuring a secure fit.
