Woodhead 330P6W 30 Amp Watertite® Pin & Sleeve Plug 2 Pole/3 Wire, 250V, Blue
Alternate Item Number: 1301500071
UPC: 786788614737
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 30 Amp, 250V, 2-Pole/3-Wire configuration
- Watertite® design with IP67 rating for dust and water protection
- Blue color coding for easy identification
- Self-adjusting split contact sleeves for reliable connection
- Latching mechanism prevents accidental disengagement
- Internal strain relief with swing-away feature and onion ring neoprene bushing for cable versatility
- Compliant with IEC 309-1 and 309-2 standards for global compatibility
- Large terminals accept conductors one or two sizes larger or smaller than standard
- Blue housing for high visibility and industry-standard color coding
- Ideal for temporary power systems, outdoor installations, and harsh industrial environments
Specifications
Amperage Rating | 30 A |
Brand Name | Woodhead |
Color | Blue |
Connection Type | Pin & Sleeve |
Current Rating | 30 A |
Environmental Conditions | IP67 |
IP Rating | IP67 |
Material | Poly |
Number of Poles | 2 |
Number Of Poles | 2-pole/3-wire |
Poles | 2P+G |
Series | Watertite |
Special Features | IEC Configuration 309-1/309-2 |
Sub Brand | Watertite |
Type | Plug |
Voltage Rating | 250 V |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
COMBINER
Solar combiners (solar panel combiner boxes) are engineered to combine power from several solar panels onto a common bus. They are specially designed for the types of wiring used in photovoltaic (PV) systems. The output would then be connected to a charge controller or inverter depending on the type of system. Solar combiners also allow for a transition to larger wires between the array and the batteries or inverter to minimize transmission voltage drop all while protecting the array. Streamline now offers a variety of premium plug and play solar combiner box solutions. Built in Streamlines UL 508-A panel shop just outside of Milwaukee Wisconsin these systems can be trusted to perform. All combiner boxes are hand-assembled using best-in-class name brand components and are built to stand up under even the harshest conditions. In addition they are highly serviceable. The polycarbonate enclosure features a full-length piano-hinged door with a non-metallic latch. They offer a variety of mounting options thanks to brass inserts on the rear wall of the enclosure and the lid. Made in the U.S.A the enclosures are UL/cUL NEMA Type 6P IP68 as well as UV and chemical resistant.
SP4
The Polaris SP4 Set Screw Plug is a replacement part that take the place of the secure removable plugs present in many Polaris pre-insulated connectors. This plug fits connectors sized for 4 AWG wires, covering the set screws used to tighten their connections. Protect the interior of your Polaris pre-insulated connectors, each port of which is pre-loaded with an oxide inhibitor to ensure a low-contact resistance connection, by guarding the set screws from outside contaminants. Polaris designs connectors for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
Frequently Asked Questions
What is the maximum voltage for this Watertite plug?
The maximum voltage for this plug is 250V.
What is the current rating for the 330P6W plug?
The maximum current per contact for this plug is 30.0A.
What is the IP rating of the Watertite plug?
The IP rating for this plug is IP67.
What type of wiring solution does this product offer?
This product is part of the Watertite® Wet-Location Wiring Solutions.
What configuration does this pin and sleeve plug have?
This is a 2-pole/3-wire pin and sleeve plug.
Is this a locking blade connector?
Yes, this connector features a locking blade.
What is the gender of the 330P6W plug?
The gender of this plug is male.
