Overview
- Nominal Output Voltage: 24VDC
- Nominal Output Current: 2.1A
- Maximum Power: 50W
- Frequency Rating: 50/64Hz
- DIN Rail Mounting for easy installation
Specifications
Amperage Rating | 2.1 A |
Application | ATM Machines;Heavy and Light Industrial Machinery;instrumentation;Scanners;Test and Measure Equipment;Vending Machines |
Application | Heavy and Light Industrial Machinery; Test and Measure Equipment; Scanners; instrumentation; ATM Machines; Vending Machines; |
Brand Name | SolaHD |
Cable Size | Input Connector size range: 22-12 AWG (0.4-3.4 mm2) for solid conductors;Output Connector size range: 20-12 AWG (0.5-3.4 mm2) for solid conductors |
Current Rating | 2.1 A |
Efficiency | 88 % typ |
Enclosure | To be installed in an enclosure |
Environmental Conditions | To be installed in a controlled environment |
Frequency | 50/64 Hz |
Frequency Rating | 50/60 HZ |
Frequency Rating, Maximum | 60 Hz |
Frequency Rating, Minimum | 50 Hz |
Fuse Rating | Internally Fused |
Height | 2.95 IN |
Length | 3.52 in |
Material | Plastic |
Mounting | DIN Rail |
Mounting Type | DIN Rail |
Phase | 1 |
Phase | Single |
Series | SVL Essential Din Rail Series |
Special Features | Universal Input; Convection cooling; DC OK LED; NEC Class 2 output; Protection: short circuit, over voltage, overload, over temperature; Two year warranty |
Special Features | Convection cooling;DC OK LED;NEC Class 2 output;Protection: short circuit, over voltage, overload, over temperature;Two year warranty;Universal Input |
Standard | UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1; UL Recognized Component, ITE for US and Canada: UL 60950-1/CSA C22.2 60950-1 2nd edition; CE: IEC/EN 60950-1 2nd edition CB Scheme, NEC Class 2 |
Standard | CE: IEC/EN 60950-1 2nd edition CB Scheme, NEC Class 2;UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1;UL Recognized Component, ITE for US and Canada: UL 60950-1/CSA C22.2 60950-1 2nd edition |
Sub Brand | Sola |
Type | SVL Essential Din Rail Series |
Voltage Rating | 24 VDC |
Wattage | 50 W |
Width | 1.18 in |
Package Dimensions (L x W x H) | 3.4 IN x 4.3 IN x 1.6 IN |
Package Dimensions (L x W x H) | 8.636 cm x 10.922 cm x 4.064 cm |
Package Weight (Imperial) | 0.500 L |
Package Weight (Metric) | 0.227 kg |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What is the input voltage range for SVL series?
The SVL series power supplies accept an AC input voltage range of 85-264 Vac and a DC input range of 120-375 Vdc.
What output voltages are available for SVL power supplies?
SVL series power supplies are available in 5 V, 12 V, 24 V, and 48 V nominal output voltage combinations.
What is the operating temperature range for SVL products?
The SVL series power supplies can operate in temperatures ranging from -20 °C to +70 °C.
What protections are included in SVL power supplies?
SVL power supplies include protection against short circuit, over voltage, overload, and over temperature conditions.
What is the warranty period for SVL series power supplies?
The SVL series power supplies come with a two-year limited warranty.
What are the dimensions of the SVL 1-24-100 model?
The SVL 1-24-100 model has dimensions of 2.95 in (H) x 0.82 in (W) x 3.52 in (D).
Do SVL power supplies have Power Factor Correction?
Yes, SVL power supplies feature Power Factor Correction, meeting EN61000-3-2 Class A, with some models having Active PFC >0.95.
What is the MTBF for SVL power supplies?
The MTBF for SVL power supplies is >350 khrs for models <120W and >700 khrs for models >120W, at 115 Vac/230 Vac @ 25 °C.
Are SVL power supplies RoHS compliant?
Yes, all SVL series power supply models are RoHS Compliant.
What is the maximum power output for the SVL 20-24-100?
The SVL 20-24-100 model has a maximum power output of 480 W.
