Contact for Pricing
Overview
- 12 VDC nominal output voltage
- 9 A nominal output current (108 W)
- 115/230 Vac dual-voltage input
- 47-63 Hz frequency range
- Single-phase power supply
Specifications
Amperage Rating | 4/2.3 AMP |
Application | Industrial Machine Control and Process, Conveying Equipment, Material Handling, Packaging Equipment |
Brand Name | SolaHD |
Cable Size | 16 - 10 AWG Solid AWG |
Efficiency | 88 PCT |
Environmental Conditions | 90 RH Humidity Range PCT |
Frequency Rating | 47 - 63 HZ |
Fuse Rating | Internally Fused |
Height | 4.88 IN |
Length | 4.55 IN |
Material | Metal Housing |
Mounting | DIN Rail |
Phase | 1 |
Special Features | Power Factor Correction (per EN61000-3-2), Auto Select 115/230 Vac, 50/60 Hz Input, DC OK Signal, Adjustable Voltage, Parallel Capability standard on all units, -10 DEG C to 60 DEG C operation without derating, Indefinite short circuit, overvoltage and overtemperature protection, Narrow width on rail for space critical applications, User-friendly front panel. |
Standard | UL (CANADA AND US), UL 508, UL 60950, CUL, CSA-C22.2, CE |
Type | SDN-P DIN Rail Series |
Voltage Rating | 115/230 VAC |
Wattage | 28.8 WAT |
Width | 3.23 IN |
Package Dimensions (L x W x H) | 7.6 IN x 7.4 IN x 3.5 IN |
Package Dimensions (L x W x H) | 19.304 cm x 18.796 cm x 8.89 cm |
Package Weight (Imperial) | 2.300 L |
Package Weight (Metric) | 1.043 kg |
