Contact for Pricing
Minimum Qty: 10
Multiplier: 1
*Contact for lower quantities*
Overview
- 3-Foot, Off-White Cat 6 UTP Patch Cord
- 24 AWG, Unshielded, Twisted Pair, Stranded CM Cable
- High-performance modular plugs with tangle-free latch
- Slender strain relief boot for high-density applications
- RapidID enabled with pre-installed barcodes for port mapping
Specifications
Application | (1) Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), 10GBASE-T (10Gigabit Ethernet over limited distances as specified in the industry 10GBASE-T standards)(2) 155 Mb/s ATM, 622 Mb/s ATM, 1.2 Gb/s ATM(3) Token ring 4/16(4) Digita |
Boot Type | Modular Plug |
Cable Type* | U/UTP |
Color | Off-White |
Conductor Material | Copper |
Jacket Material | Polyvinyl Chloride (PVC) |
Length | 3.00 |
Material* | Copper |
Outside Diameter | 0.235 in |
Outside Diameter | 5.969 mm |
Performance Level* | Category 6 |
Plug Type | Modular Plug |
Special Features | NULL |
Standard | Exceeds all ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA standards for all channel and component frequencies up to 500 MHz;Meets ANSI/TIA-1096-A requirements;Meets IEC 60603-7;Rated for 2500 cycles with IEEE 802.3af / 802.3at and 802.3bt type 3 a |
Temperature Rating, Maximum | 140 F |
Temperature Rating, Maximum | 60 C |
Temperature Rating, Minimum | 140 F |
Temperature Rating, Minimum | 60 C |
Type | Patch Cord |
Wire Size | 24 AWG |
Package Dimensions (L x W x H) | 8.95 IN x 8.65 IN x 0.65 IN |
Package Weight (Imperial) | 0.135 lbs |
Similar Products
Frequently Asked Questions
How many mating cycles are the connectors rated for?
The connectors are rated for 2500 mating cycles, ensuring long-lasting performance.
What is the maximum operating temperature for the connectors?
The connectors are rated for a maximum operating temperature of 75º C.
What is the warranty period for the Mini-Com Solution?
The Mini-Com Solution comes with a 25-year system warranty when used end-to-end.
What is the smallest diameter for Category 6A patch cords?
The smallest diameter for Category 6A patch cords is 0.185 inches (4.7mm).
What is the rated bandwidth for Category 6 cable?
Category 6 cable has a rated bandwidth of 550 MHz.
What types of applications does the copper cabling support?
The copper cabling supports applications such as Power over Ethernet, wireless connectivity, intelligent lighting, security cameras, and audio/visual systems.
What is the installation method for the Mini-Com jacks?
The Mini-Com jacks feature tool-less termination, which maintains conductor twist for reliable performance.
How many times can the Mini-Com jacks be reterminated?
The Mini-Com jacks can be reterminated up to 20 times.
What is the compatibility of the NetKey jack modules?
NetKey jack modules are designed for compatibility with any keystone opening.
What safety features do the connectors have?
The connectors feature integrated arc suppression technology for enhanced safety.
