Panduit UTP28X25MGR - The TX6A-28 Cat 6A UTP Patch Cord is a 25-Meter, 0.185-inch (4.7mm) diameter, Green cord constructed of 28 AWG unshielded, twisted pair, solid, CM/LSZH cable with high-performance modular plugs. Its compact 28 AWG design simplifies installation and management. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Panduit

UTP28X25MGR

UPC: 074983005697

Documents & Media
BrochureTechnical BulletinTechnical DrawingFull Engineering DrawingInstallation InstructionsSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 1

*Contact for lower quantities*

Overview

The Panduit TX6A-28 Cat 6A UTP Patch Cord (SKU: UTP28X25MGR) is a 25-meter, green, unshielded twisted pair patch cord designed for high-performance network infrastructure. Constructed with 28 AWG solid CM/LSZH cable, this cord offers a compact 0.185-inch (4.7mm) diameter, significantly simplifying installation and cable management in dense environments. The high-performance modular plugs are integrated with a tangle-free latch mechanism, preventing snags during installation and ensuring a quick, secure release for streamlined moves, adds, and changes. This feature is crucial for maintaining network uptime and reducing labor costs in data centers and enterprise networks. Furthermore, the TX6A-28 patch cord is enabled with Panduit's RapidID technology. Each cord comes with pre-installed barcodes, allowing for effortless port mapping and network documentation when used in conjunction with RapidID software. This integrated solution enhances network visibility and simplifies troubleshooting, making it an ideal choice for modern IT professionals seeking efficiency and accuracy in network deployment and maintenance. Manufactured in the US, this Cat 6A compliant cord supports 10 Gigabit Ethernet applications, ensuring future-proof connectivity.
  • 25-meter Cat 6A UTP patch cord in green
  • Compact 0.185-inch (4.7mm) diameter with 28 AWG solid CM/LSZH cable
  • Tangle-free latch design for easy installation and release
  • RapidID enabled with pre-installed barcodes for simple port mapping
  • Supports 10 Gigabit Ethernet applications

Specifications

Application
(1) 10GBASE-T Ethernet (2) Data center I/O Consolidation (3) Data center server virtualization (4) Backbone aggregation (5) Parallel processing and high speed computing
Boot Type
Modular Plug
Cable Type*
F/UTP
Color
Green
Conductor Material
Copper
Jacket Material
LSZH Material
Material*
Copper
Outside Diameter
0.185 in
Outside Diameter
4.699 mm
Performance Level*
Category 6A
Plug Type
Modular Plug
Standard
Meets ANSI/TIA-1096-A (formerly FCC Part 68), Meets IEC 60603-7, Supports IEEE 802.3af/802.3at (48 cables in a bundle) and 802.3bt type 3 and type 4 (24 cables in a bundle) PoE applications, cULus Listed, UL 1863 and CAN/CSA-C22.2 (UL File E129886), RoHS c
Temperature Rating, Maximum
167 F
Temperature Rating, Maximum
75 C
Temperature Rating, Minimum
167 F
Temperature Rating, Minimum
75 C
Type
Patch Cord
Wire Size
28
Package Dimensions (L x W x H)
14 IN x 17 IN x 1.5 IN
Package Weight (Imperial)
1.27 lbs
