Contact for Pricing
Overview
- 45 RU capacity for extensive equipment storage
- 800mm W x 1200mm D dimensions for ample space
- Split perforated rear doors minimize door swing footprint
- Vertically split hinged side panels for easy access
- Adjustable front and rear equipment rails for flexible mounting
Specifications
Application | NA |
Color | Black |
Depth | 49.96 In. |
Finish | Powder-coated |
Material | Steel |
Rack Spaces* | 45 |
Standard | RoHS Compliant, EIA-310-E, TIA/EIA-942, UL2416 |
Type | S-Type Cabinet |
Width | 31.4 In. |
Package Dimensions (L x W x H) | 49 IN x 30 IN x 95 IN |
Package Weight (Imperial) | 447 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What are the load capacities of the cabinet?
The S-Type Universal Cabinet has a static load rating of 3000 lbs and a rolling load rating of 2500 lbs.
What are the available cabinet widths and depths?
Cabinets are available in widths of 600mm (23.6 in), 700mm (27.6 in), 800mm (31.5 in) and depths of 1070mm (42.12 in), 1200mm (47.21 in).
Are casters and leveling legs included with the cabinet?
Yes, heavy-duty casters and leveling legs are included as standard features for easy positioning and stability.
What is the application environment for these cabinets?
These are indoor 19 in rack mount equipment enclosures, designed for network or server applications.
Can S-Type cabinets be ganged with other cabinet types?
Yes, N-Type and S-Type Cabinets can be ganged together for a complete streamlined appearance.
How are the S-Type Universal Cabinets shipped?
The cabinet ships assembled, one per pallet.
What industry standards do these cabinets comply with?
The cabinets comply with EIA-310-E, TIA/EIA-942, and UL2416 standards.
How are the cabinets bonded for safety?
Cabinets and accessories are integrally bonded without the use of grounding wires, providing a safe and reliable network.
What are the available RU heights for the cabinets?
S-Type Universal Cabinets are available in 42 RU, 45 RU, and 48 RU heights.
What materials are the cabinets made from?
The cabinets are made from steel with a durable black or white polyester epoxy powder coat finish.
How to Install the Net-Access S-Type Universal Cabinet
This guide provides step-by-step instructions for installing the Net-Access S-Type Universal Cabinet, including leveling, securing, and grounding procedures.
Estimated time: 1h
Tools needed:
Phillips screwdriver, Flatblade screwdriver, 15mm socket wrench, 6mm Allen key, T25 Torx bit
Supplies needed:
Mounting screws, Grounding lug, Shipping hold down brackets
- Remove Packaging Material
Remove all stretch wrap and protective cardboard from the outside of the cabinet. Use two people to carefully lift and remove the cabinet from the pallet.
- Level the Cabinet
Ensure that the leveling legs are fully retracted. Slide the cabinet into its final position and lower the leveling legs using a 6mm Allen key until the cabinet weight is fully supported. Adjust the leveling legs to ensure the cabinet is level front-to-back and side-to-side.
- Secure the Cabinet to the Floor
If necessary, secure the shipping hold down brackets at the front and rear of the cabinet. Attach anchors to the floor with appropriate hardware for your type of floor using M10 hex head screws and a 15mm socket wrench.
- Ground the Cabinet
Attach a grounding lug or grounding bar at any of the indicated locations using an M5 bonding screw to ensure proper grounding.
- Install Equipment Rails
Loosen the M10 hex head screws at the top and bottom of the equipment rail. Adjust the equipment rail to the desired position and tighten the screws to 30.0 +/- 5.0 N-m.
