Contact for Pricing
Overview
- 45 RU capacity for extensive IT equipment
- 800mm W x 1070mm D dimensions provide ample space
- Split perforated rear doors minimize door swing footprint
- Vertically split hinged side panels for easy access
- Adjustable front and rear equipment rails for flexible mounting
Specifications
Application | NA |
Color | Black |
Depth | 43.89 In. |
Finish | Powder-coated |
Material | Steel |
Material | Powder-coated steel |
Rack Spaces* | 45 |
Size | 85" H x 31.5" W x 42" D (800mm W x 1070mm D) |
Standard | RoHS Compliant, EIA-310-E, TIA/EIA-942, UL2416 |
Type | S-Type Cabinet |
Width | 31.4 In. |
Package Dimensions (L x W x H) | 49 IN x 30 IN x 95 IN |
Package Weight (Imperial) | 432 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What are the available RU heights for S-Type cabinets?
S-Type Universal Cabinets are available in 42 RU, 45 RU, and 48 RU heights.
Are PDU brackets included with the S-Type cabinet?
Yes, one set of PDU Brackets (SPDUBRK) is included as a standard feature.
Are casters and leveling legs included with the cabinet?
Yes, heavy-duty casters and leveling legs are included as standard features.
What are the available widths and depths for S-Type cabinets?
Available widths are 600mm (23.6 in), 700mm (27.6 in), 800mm (31.5 in). Depths are 1070mm (42.12 in) and 1200mm (47.21 in).
What type of doors are standard on S-Type Universal Cabinets?
Standard features include a Front Single Hinge Door and Split Perforated Rear Door with 69% open perforation.
Do the S-Type cabinets require grounding wires for bonding?
No, the cabinets and accessories are integrally bonded without the use of grounding wires.
Can S-Type cabinets be ganged with N-Type cabinets?
Yes, N-Type and S-Type Cabinets can be ganged together for a complete streamlined appearance.
How are the S-Type Universal Cabinets shipped?
The cabinet ships assembled, one per pallet.
What industry standards do these cabinets comply with?
The S-Type Universal Cabinets comply with EIA-310-E, TIA/EIA-942, and UL2416 standards.
What materials are S-Type Universal Cabinets made from?
The cabinets are made from steel with a durable black or white polyester epoxy powder coat finish.
How to Install the Net-Access S-Type Universal Cabinet
This guide provides step-by-step instructions for installing the Net-Access S-Type Universal Cabinet, including leveling, mounting, and securing the cabinet.
Estimated time: 1h
Tools needed:
Phillips screwdriver, Flatblade screwdriver, 22mm socket wrench, 15mm socket wrench, 13mm socket wrench, 8mm socket wrench, 48” level, 7mm socket wrench, T30 Torx bit, T25 Torx bit, 6mm Allen key, 2.5mm Allen key, Wire cutter
Supplies needed:
Mounting screws, Shipping hold down brackets, Anchors for floor mounting, Grounding lug or bar, M5 bonding screws
- Remove packaging material
Inspect the cabinet for damage, then remove all stretch wrap and protective cardboard from the outside. Remove all shipping brackets and hold down brackets if necessary.
- Level the cabinet
Ensure that the leveling legs are fully retracted. Slide the cabinet into its final position and lower the leveling legs using a 6mm Allen key until the cabinet is fully supported. Adjust the legs to ensure the cabinet is level both front-to-back and side-to-side.
- Secure the cabinet to the floor
If necessary, secure the shipping hold down brackets at the front and rear of the cabinet. Use appropriate hardware to attach the anchors to the floor based on your floor type.
- Ground the cabinet
Attach a grounding lug or grounding bar at any of the designated locations using M5 bonding screws. Ensure the grounding location is indicated by the universal ground symbol.
- Gang multiple cabinets (if applicable)
Ensure all cabinets are level. Secure ganging brackets to the front and rear of the cabinets using M6 Torx screws. Do not cinch the cabinets together with the ganging brackets.
