Overview
- 2/0 AWG wire compatibility for heavy-duty applications
- 5/16" (8mm) stud size for secure mounting
- Non-insulated design for optimal conductivity
- Brazed seam construction prevents barrel splitting
- UL and CSA certified for up to 2000V (UL 486A/B)
- UL and CSA rated up to 2000V per UL 486A/B
- Maximum operating temperature of 302°F (150°C)
- Ideal for high-vibration applications
Specifications
Amperage Rating | NA A |
Angle* | Straight |
Barrel Type* | Seamless Tubular |
Cable Size | 2/0 AWG AWG |
Color | Metallic |
Connection | Beveled |
Connection Type | Tubular Ring Terminal |
Insulation | Non-Insulated |
Material | Tin-plated Copper |
Material | Copper |
Mounting | 11/16 In. |
Mounting Type | Stud Mount |
Mounting Type | Stud |
Number Of Holes | NA |
Series | S2/0-56R-X |
Series | S |
Series | S2/0 |
Size | 2/0 AWG wire, 5/16" (8mm) stud |
Size | 5/16" (8 mm) stud size |
Size | 2/0 AWG, 5/16" (8mm) stud |
Size | 2/0 AWG, 5/16" Stud |
Size | 2/0 AWG, 5/16 stud size |
Special Features | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
Stud Size | 5/16 In. |
Type | Loose Piece Ring Terminal |
Voltage Rating | 2000 V |
Voltage Rating | NA V |
Package Dimensions (L x W x H) | 4.15 IN x 2.15 IN x 2.1 IN |
Package Weight (Imperial) | 0.6 lbs |
