Contact for Pricing
Overview
- UL 1400-2 listed for Class 4 power cabling compliance
- 18 AWG stranded copper conductors for flexibility and current capacity
- Pre-terminated ferrules on both ends for quick, reliable installation
- Flame-retardant CMP-rated PVC jacket for plenum-rated spaces
- Factory-cut to predetermined lengths for consistent performance
Specifications
Color | White |
Connection Type | ferrules |
Jacket Material | Polyvinyl Chloride (PVC) |
Material | PVC |
Outside Diameter | 0.197 in |
Outside Diameter | 5.0038 mm |
Performance Level* | Class 4 |
Poles | 2P |
Series | PXUP |
Size | 18 AWG |
Standard | UL-1400-2 (Class 4), NEC Article 725, UL 13 type CL3P NEC Article 726, UL 1400-2 Type CL4P, NEC Article 800, UL 444 CMP |
Temperature Rating, Maximum | 167 F |
Temperature Rating, Maximum | 75 C |
Temperature Rating, Minimum | 167 F |
Temperature Rating, Minimum | 75 C |
Type | FMPS Power Patch Cord |
Package Dimensions (L x W x H) | 8.95 IN x 8.75 IN x 0.65 IN |
Package Dimensions (L x W x H) | 22.733 cm x 22.225 cm x 1.651 cm |
Package Weight (Imperial) | 0.1140 L |
Package Weight (Metric) | 0.0517 kg |
TY29MX
High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)
TYH27M
Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)
A238
Two Gang Outlet Box, Volume 38 Cubic Inches, Length 3.844 Inches, Width 3.53 Inches, Depth 3.45 Inches, Number of Knockout 5, Knockout Size 1/2 Inch, 3/4 Inch, and 1 Inch, Color Blue, Material PVC
CPP24FMWBLY
The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.
SVNDZ-P167GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color GraySVNDZ-P137GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 13.5, Fits to Conduit Size NW/Metric 17/20, Color Gray
MPNY-1000-0-C
Cable Tie Mounting Base, UV Black Nylon 6.6 for Temperatures up to 70 Degrees Celsius (158 F), Length of 25.14mm (0.99 Inches), Width of 25.14mm (0.99 Inches), Height of 5.08mm (0.198 Inches), Mechanical Strength 50 Newtons (11 Pounds), Hole Size #6, Synthetic Rubber Mounting Method, 100 Pack
Frequently Asked Questions
What standards does the Class 4 Power Patch Cord comply with?
The cord complies with UL 1400-2 for Class 4 cabling, NEC Article 725, UL 13 type CL3P, NEC Article 726, UL 1400-2 type CL4P, NEC Article 800, and UL 444 CMP.
What is the operating temperature range for the patch cord?
The operating temperature range for the patch cord is -4ºF to 167ºF (-20ºC to 75ºC).
What is the flame rating of the power patch cord?
The power patch cord has a Plenum (CMP) flame rating.
What is the voltage rating for the Class 4 Power Patch Cord?
The voltage rating for the Class 4 Power Patch Cord, according to UL 1400-2, is 450 Vrms.
What type of conductors and jacket does the cord have?
The cord has 18 AWG stranded tinned copper conductors insulated with PVC, covered by a flame retardant (CMP) PVC jacket.
What are the typical applications for this power patch cord?
It is used in indoor Class 4 power distribution, Fault Managed Power Systems, and remote powering optimized for the Panduit Class 4 FMPS.
What is the minimum bend radius for fixed applications?
The minimum bend radius for fixed applications is 5 times the cable diameter.
What is the minimum bend radius for moving applications?
The minimum bend radius for moving applications is 10 times the cable diameter.
What is the outer jacket diameter of the cable?
The outer jacket diameter of the cable is 0.197 in. (5.0mm) nominal.
Is the power patch cord part of a larger system?
Yes, it is a component of an end-to-end Class 4 Fault Managed Power System (FMPS).
How to Install the Panduit FMPS Transmitter Chassis and Power Supply
This guide provides step-by-step instructions for the safe installation and initial setup of the Panduit Fault Managed Power System (FMPS) Transmitter Chassis and its Power Supply Modules. Learn to ground, mount, and connect input power to the system.
Estimated time: 1h
Tools needed:
Screwdrivers (#2 Phillips, #3 Phillips, Slotted), Wire stripper, Wrenches and/or pliers, Wire cutters, Compression crimp tools, Multimeter, Label maker
Supplies needed:
Field wiring, Copper patch wire, Cabinet mounting screws (if applicable), Terminal connectors, Strain relief bar or shelf (for 4-post flush mount), Power cords (as needed for input power source), Cable management materials (e.g., cable ties), Ferrules (16AWG, 18AWG)
- Prepare for Installation and Ensure Safety
Always follow safety and lockout/tagout procedures when working on or near electrical systems. Ensure installation is performed by skilled personnel and complies with all local codes. Verify that the rack has appropriate grounding to earth ground before proceeding, as proper grounding is critical for FMPS operation. Do not apply power until all hardware installation is complete.
- Ground and Mount the Transmitter Chassis
Attach the side brackets to the Transmitter Chassis at the appropriate position (B or C for 2-post, A for 4-post flush mount). For 4-post flush mounting, install a strain relief bar or shelf in the back of the rack/cabinet to support the chassis. Mount the Transmitter Chassis to the rack using the three provided rack mounting screws and the grounding screw. Ensure the grounding screw properly grounds the chassis to the rack.
- Install Power Supply Module(s)
Ensure PDU outputs and/or power cords are not supplying power. If installing additional Power Supply Modules, first remove any Power Supply blanking panels. Insert each Power Supply Module into an empty slot in the back of the Transmitter Chassis and slide it forward until it clicks. Gently pull the handle to verify the latches are engaged. Ensure no blockages are in front of the dual fans for proper airflow.
- Connect Input Power to Power Supply Module(s)
With all power sources disconnected, connect the C-19 end of the power cord (provided with the Power Supply Module) into the Power Supply Module. Connect the C-20 plug end into a properly sized PDU outlet or an appropriate wiring device. Ensure all connections are secure before applying power to the system at the end of the overall hardware installation.
