Panduit PWBTB12CBL The Wire Basket Trapeze Bracket w/ Center Hole is used in cable routing systems to…
UPC: 613056911055
Contact for Pricing
Minimum Qty: 2
Multiplier: 2
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 12-inch width for Panduit Wire Basket compatibility
- Center hole design for single or dual threaded rod mounting
- Side holes accommodate 1/2" or M12 threaded rods
- Black powder-coated finish for corrosion resistance
- Sold in packages of two; hardware kits sold separately
Specifications
Application | Data Centers, Connected Buildings, and Industrial Automation Applications for all Panduit Wire Basket Applications |
Color | Black |
Color* | Black |
Finish | Powder-coated |
Length | NA In. |
Material | Steel |
Mounting Type | Threaded Rod (Dual or Single) |
Series | PWBTB |
Size | 12 inch |
Type | Wire Basket Trapeze |
Width | NA In. |
Package Dimensions (L x W x H) | 24 IN x 5 IN x 2 IN |
Package Dimensions (L x W x H) | 60.96 cm x 12.7 cm x 5.08 cm |
Package Weight (Imperial) | 1.0900 L |
Package Weight (Metric) | 0.4944 kg |
CCFGSX46
The nVent CCFGSX46 cable gland is designed for robust and secure cable management in industrial applications. Engineered to withstand harsh environmental conditions, this cable gland ensures reliable performance and protection for cables in demanding settings. Its durable construction and precise design make it ideal for use in manufacturing, automation, and other industrial environments where cable integrity is critical. The nVent CCFGSX46 provides a secure seal, preventing ingress of dust, moisture, and other contaminants, while maintaining flexibility for easy installation and maintenance. Trust nVent for high-quality cable management solutions that enhance operational efficiency and safety.
61214
ITW Sammys 1-1/2" Code Compliance Kit supplied in a poly bag. The sheet identifies it as catalog number 61214. Country of origin is USA.
PWBTB4CWH
The Wire Basket Trapeze Bracket w/ Center Hole is used in cable routing systems to support a 4 inch wide Wire Basket from either dual or single threaded rod. The hardware for attaching the bracket is sold separately. The Trapeze Bracket comes in white powder-coated finish and is sold in packages of two.
Frequently Asked Questions
What size wire basket does this bracket support?
This Panduit trapeze bracket is designed to support a 12 inch wide Wire Basket.
How is this bracket attached to the support structure?
The bracket features a center hole and is used to support the wire basket from either dual or single threaded rod.
Does the hardware for mounting the bracket come included?
No, the hardware for attaching the bracket to the threaded rod is sold separately.
What is the finish of the Panduit PWBTB12CBL bracket?
The Panduit PWBTB12CBL Wire Basket Trapeze Bracket comes in a black powder-coated finish.
How many brackets are included in a package?
The Wire Basket Trapeze Bracket is sold in packages of two.
How to Install the Panduit Wire Basket Trapeze Bracket
This guide provides instructions for installing the Panduit Wire Basket Trapeze Bracket using either traditional or center hole mounting methods. Ensure proper support and bonding for a secure installation.
Estimated time: 30m
Tools needed:
Wrench
Supplies needed:
1/2 inch or M12 Threaded Rods, Nuts (customer supplied), Washers (customer supplied), Panduit Wire Basket Hangers (PWBHK**, sold separately), Threaded Rod Cover (optional)
- Prepare Threaded Rods
Select 1/2 inch or M12 threaded rods of appropriate length for your installation. Ensure the rods are cut to the required size and are ready for mounting.
- Attach Trapeze Bracket
Secure the trapeze bracket to the threaded rods using customer-supplied nuts and washers. Choose either the traditional installation method (using outer holes) or the center hole installation method, depending on your wire basket's center line wire clearance. Tighten nuts securely with a wrench.
- Connect Wire Basket
Attach the wire basket to the trapeze bracket using two Panduit Wire Basket Hangers (PWBHK**, sold separately). Ensure the basket is properly seated and secured to the bracket.
- Final Adjustments and Best Practices
If using a center hole installation with a center line wire, shift the trapeze bracket or wire basket as needed to provide necessary clearance. For best practice, apply a threaded rod cover (e.g., TRC18FR-X20Y) for center hole installations. Additionally, bond pathway sections as recommended for agency approvals and overall system integrity.
