Panduit PWBCVRLCK4X18PG Our Cover Retention Straps secure your metal covers in place, preventing unathorized…
UPC: 613056897991
Contact for Pricing
Minimum Qty: 3
Multiplier: 1
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Tamper-resistant design with specialized security screw and tool for enhanced security.
- Specifically designed for 4" H x 18" W Panduit wire basket metal covers.
- Pre-Galvanized (PG) finish offers corrosion resistance.
- Recommended 6 straps per 10-foot length of basket for optimal coverage.
- Prevents unauthorized cable access in shared environments.
Specifications
Color* | Gray |
Length | 21.48 in |
Length | 545.592 mm |
Size | 4" H x 18" W |
Type | Wire Basket Tamper-Resistant Cover Retention Strap |
Package Dimensions (L x W x H) | 24 IN x 8 IN x 2 IN |
Package Dimensions (L x W x H) | 60.96 cm x 20.32 cm x 5.08 cm |
Package Weight (Imperial) | 1.6600 L |
Package Weight (Metric) | 0.7530 kg |
A238
Two Gang Outlet Box, Volume 38 Cubic Inches, Length 3.844 Inches, Width 3.53 Inches, Depth 3.45 Inches, Number of Knockout 5, Knockout Size 1/2 Inch, 3/4 Inch, and 1 Inch, Color Blue, Material PVC
AFR4BCBL6
Above floor raceway is a non-metallic, 4 channel surface raceway used to route, protect, and conceal data, voice, video, fiber optic and power cabling over floors. The structurally engineered design is ADA compliant, tamper resistant and made of rigid PVC. It is 6 feet long and is black
PWBCVRLCK2X12PG
Our Cover Retention Straps secure your metal covers in place, preventing unathorized cable access in shared spaces. The Tamper-Resitant design includes a speciality screw and bit hardware. Specifically designed to fit 2" H x 12" W basket. Recommended 6 straps per one 10 foot length of covered basket. Comes in Pre-Galvanized finish.
PWBCVRLCK4X36PG
Our Cover Retention Straps secure your metal covers in place, preventing unathorized cable access in shared spaces. Our Tamper-Resitant design includes a speciality screw and bit hardware. Specifically designed to fit 4" H x 36" W basket. Recommended 6 straps per one 10 foot length of covered basket. Comes in Pre-Galvanized finish.
PWBCVRLCK6X8PG
Our Cover Retention Straps secure your metal covers in place, preventing unathorized cable access in shared spaces. Our Tamper-Resitant design includes a speciality screw and bit hardware. Specifically designed to fit 6" H x 8" W basket. Recommended 6 straps per one 10 foot length of covered basket. Comes in Pre-Galvanized finish.
PWBCOP12PG
Wire Basket Cable Organizer neatly separates cabling inside the width of 12" (300mm) pathway. The posts are preinstalled and the pre-galvanized plate can install over metal or plastic tray liner. It is packaged in quantities of 1.
PWBCOP18PG
Wire Basket Cable Organizer neatly separates cabling inside the width of 18" (450mm) pathway. The posts are preinstalled and the pre-galvanized plate can install over metal or plastic tray liner. It is packaged in quantities of 1.
PWBCOP24PG
Wire Basket Cable Organizer neatly separates cabling inside the width of 24" (600mm) pathway. The posts are preinstalled and the pre-galvanized plate can install over metal or plastic tray liner. It is packaged in quantities of 1.Frequently Asked Questions
What is the Panduit Wire Basket System used for?
The system routes and manages copper, fiber optic, or power cables in data centers, connected buildings, and industrial environments.
What materials are used for the wire baskets?
Baskets are made of steel wire. Finishes include powder-coated black or white, electro zinc plated, or zinc plated (pre-galvanized).
What are the available widths for wire basket pathway sections?
Pathway sections are available in widths of 4, 6, 8, 12, 18, 24, 30, and 36 inches.
What are the available sidewall heights for wire baskets?
The wire baskets are available in 2, 4, or 6 inch sidewall heights.
What is the standard length of a wire basket section?
Each wire basket section is 118.33 inches long.
What types of mounting brackets are available?
Trapeze, cantilever, and wall mount brackets are available to support the system.
Is the Wire Basket System UL Listed?
Yes, it is UL Listed for use as an Equipment Grounding Conductor according to NFPA 70 Sections 392.6(A) and 392.6(B) and NEMA VE1.
What finishes are available for the wire basket system components?
Baskets, accessories, and components are available in black, electro zinc, pre-galvanized, or white finishes.
What types of splice connections are available?
Bolted style, push-on style, and expansion splice bar connections are available for the system.
What is the PWBCVRLCK4X18PG product?
The PWBCVRLCK4X18PG is a Cover Retention Strap, 4 inches high by 18 inches wide, with a pre-galvanized finish.
How to Install the Panduit Wire Basket Metal Cover with Retention Strap
This guide provides step-by-step instructions for installing the Panduit Wire Basket Metal Cover, including attaching the retention straps and securing the cover to the wire basket.
Estimated time: 15m
Tools needed:
Security screw Tool
Supplies needed:
Security screw
- Insert Metal Cover onto Wire Basket
Carefully place and insert the metal cover onto the wire basket, ensuring it aligns properly with the basket's structure.
- Assemble and Secure First Retention Strap
Assemble the swing arm to the trapeze bracket to form the first retention strap assembly. Slide this retention strap assembly over the metal cover, positioning it correctly. Use the provided security screw and security screw tool to firmly secure this retention strap assembly to the wire basket, locking the metal cover in place.
- Assemble and Secure Second Retention Strap
Repeat the process from Step 2 for the second retention strap assembly. Assemble the swing arm to the trapeze bracket, slide the assembly over the metal cover, and secure it with the remaining security screw and tool. Ensure both retention straps are tightly fastened for complete cover security.
