Panduit PUY6AV04WH-EG - The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE jacket. The white, LSZH (IEC 60332-3, EuroClass Cca-s1a,d1,a1) cable is supplied 305 meters (1,000 feet) to a reel.
Panduit

PUY6AV04WH-EG

UPC: 613056454361

Documents & Media
Specification SheetVideo Clip

Contact for Pricing

Minimum Qty: 48

Multiplier: 24

*Contact for lower quantities*

Overview

Panduit TX6A Cat 6A U/UTP copper cable (SKU: PUY6AV04WH-EG) delivers high-performance, unshielded twisted-pair connectivity for mission-critical 10GBASE-T networks. Constructed with 23 AWG solid copper conductors and HDPE insulation, this cable features a cross divider to separate pairs, reducing crosstalk and ensuring signal integrity. The Vari-MaTriX Tape wrap and flame-retardant HDPE jacket provide mechanical protection and fire safety compliance to IEC 60332-3 (EuroClass Cca-s1a,d1,a1). Designed for PoE applications requiring higher current levels, including IEEE 802.3bt-2018 compliant systems, the TX6A supports up to 100m channel lengths for A/V and high-bandwidth environments. The low outside diameter (0.272" for Plenum, 0.291" for Riser) enhances cable density and simplifies installation in tight conduits or cable trays. Supplied on a 305m (1,000 ft) reel, this white LSZH cable meets ANSI/TIA 568.2-D standards and is ETL verified for Category 6A component compliance. Key features include: - 23 AWG solid copper conductors with HDPE insulation - Cross divider for pair separation and crosstalk reduction - Vari-MaTriX Tape wrap and flame-retardant HDPE jacket - LSZH jacket compliant with IEC 60332-3 (EuroClass Cca-s1a,d1,a1) - 305m (1,000 ft) reel for efficient deployment - ETL verified for Category 6A compliance - Supports 10GBASE-T and PoE applications Ideal for data centers, enterprise networks, industrial automation, and wireless access points where reliability and performance are critical. The TX6A U/UTP cable ensures consistent data transmission with minimal interference, making it a dependable choice for high-density installations.
  • 23 AWG solid copper conductors with HDPE insulation
  • Cross divider for pair separation and crosstalk reduction
  • Vari-MaTriX Tape wrap and flame-retardant HDPE jacket
  • LSZH jacket compliant with IEC 60332-3 (EuroClass Cca-s1a,d1,a1)
  • ETL verified for Category 6A compliance
  • Supports 10GBASE-T and IEEE 802.3bt-2018 PoE applications
  • 305m (1,000 ft) reel for efficient deployment

Specifications

Color
White
Material
Copper, HDPE, LSZH
Series
TX6A Cat 6A U/UTP
Size
23 AWG
Package Dimensions (L x W x H)
15.75 IN x 15.75 IN x 9.65 IN
Package Weight (Imperial)
35 lbs
The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel

PFC6X04WH-CEG

The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel
The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.

PFR6C04WH-UG

The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.
Enhanced copper cable, category 5e UTP, plenum (CMP), 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, white.

PUP5504WH-UY

Enhanced copper cable, category 5e UTP, plenum (CMP), 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, white.
Cat 6A Advanced MaTriX 4-pair 23 AWG copper cable, U/UTP, LSZH (Low Smoke Zero Halogen, IEC60332-1 and 60332-3) rated, White, Euro pallet, 1000ft/305m.

PUL6AM04WH-CEG

Cat 6A Advanced MaTriX 4-pair 23 AWG copper cable, U/UTP, LSZH (Low Smoke Zero Halogen, IEC60332-1 and 60332-3) rated, White, Euro pallet, 1000ft/305m.
Copper cable, premium category 6 UTP, riser (CMR), 4-pair, conductors are 23 AWG construction with HDPE insulation, twisted in pairs, separated by an integrated pair divider and protected by a flame-retardant PVC jacket, white.

PUR6504WH-UY

Copper cable, premium category 6 UTP, riser (CMR), 4-pair, conductors are 23 AWG construction with HDPE insulation, twisted in pairs, separated by an integrated pair divider and protected by a flame-retardant PVC jacket, white.
The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 500m on a reel.

PUL6004WH-EDY

The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 500m on a reel.
The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m in an easy payout carton.

PUR6C04WH-F

The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m in an easy payout carton.
The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m on a reel in a box.

PUL6004WH-EY

The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m on a reel in a box.
The TX7000 Cat 7 S/FTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are individually shielded, twisted in pairs and covered by an overall braided shield and a HDPE flame retardant (LSZH), White jacket. Packaged 1640FT/500M on a reel

PSL7004WH-CED

The TX7000 Cat 7 S/FTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are individually shielded, twisted in pairs and covered by an overall braided shield and a HDPE flame retardant (LSZH), White jacket. Packaged 1640FT/500M on a reel
Shielded copper cable, category 5e F/UTP, plenum (CMP), conductors are 24 AWG construction with FEP insulation, twisted in pairs, surrounded by an overall polyester aluminum foil with stranded copper drain wire and protected by a low smoke flame-retardant PVC jacket, white.

PFP5504WH-UY

Shielded copper cable, category 5e F/UTP, plenum (CMP), conductors are 24 AWG construction with FEP insulation, twisted in pairs, surrounded by an overall polyester aluminum foil with stranded copper drain wire and protected by a low smoke flame-retardant PVC jacket, white.
The TX6A Cat 6A U/UTP LSZH copper cable is constructed of 26 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs, separated by a cross divider and covered by a HDPE flame retardant (LSZH), White jacket. Packaged 1000ft/305m on a reel

PUL6ASD04WH-EG

The TX6A Cat 6A U/UTP LSZH copper cable is constructed of 26 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs, separated by a cross divider and covered by a HDPE flame retardant (LSZH), White jacket. Packaged 1000ft/305m on a reel
Copper cable, category 6A U/UTP, plenum (CMP), 4-pair, conductors are 23 AWG with FEP insulation, twisted in pairs, separated by an integrated pair divider, surrounded by an advancedmatrix tape and protected by a flame-retardant PVC jacket, white.

PUP6AM04WH-UGA

Copper cable, category 6A U/UTP, plenum (CMP), 4-pair, conductors are 23 AWG with FEP insulation, twisted in pairs, separated by an integrated pair divider, surrounded by an advancedmatrix tape and protected by a flame-retardant PVC jacket, white.

Frequently Asked Questions

What channel performance standards does the cable exceed?

The cable exceeds ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA Standards for channel performance.

What is the flame rating for the LSZH Cca cable?

The LSZH Cca cable has a EuroClass Cca-s1a-d1-a1 flame rating, meeting IEC 60332-3-22, 60754-2, and 61034-2 standards.

What is the minimum bend radius for this cable?

The minimum bend radius for the cable is 4 times its cable diameter.

What is the maximum installation tension for the cable?

The maximum installation tension for the cable is 25 lbf (110 N).

What is the recommended temperature range for installation?

The recommended temperature range during installation is 0°C to 60°C (32°F to 140°F).

What is the operating temperature range for LSZH cables?

LSZH cables can operate from -20°C to 75°C (-4°F to 167°F).

Is this cable compliant with Power over Ethernet standards?

Yes, the cable meets IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt for PoE applications.

What is the maximum operating voltage for this cable?

The maximum operating voltage for the cable is 80V.

What is the nominal diameter of the LSZH Cca cable?

The nominal cable diameter for LSZH Cca versions is 6.7mm (0.265 inches).

What is the cable category and performance?

This is a Category 6A/Class EA cable, certified for channel performance up to 100m and supporting 10GBASE-T transmission up to 650 MHz.
