Panduit PUL6004WH-EY - The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 1000 ft./305m on a reel in a box.
Panduit

PUL6004WH-EY

UPC: 074983717521

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 18

Multiplier: 18

*Contact for lower quantities*

Overview

The Panduit TX6000 Cat 6 U/UTP LSZH copper cable (SKU: PUL6004WH-EY) is engineered for reliable data transmission in demanding environments. Constructed with 23 AWG copper conductors, this cable features HDPE insulation for each conductor. The four pairs of conductors are twisted and separated by a cross divider, ensuring signal integrity and minimizing crosstalk. All pairs are enclosed within a flame-retardant HDPE (LSZH) jacket, providing enhanced safety in case of fire. This cable is specified for Category 6 performance, supporting data rates up to 1000 Base-T (Gigabit Ethernet). It is ETL verified to the TIA-568.2-D Category 6 standard, guaranteeing electrical performance characteristics across the specified frequency range. The cable is designed for applications requiring robust data handling, including voice, video, and data transmission concurrently. It is also suitable for PoE applications. The white jacket facilitates easy identification and cable management. Packaged conveniently on a 1000 ft. (305m) reel in a box, it minimizes tangles during installation. The robust box design further aids in a smooth installation process. Manufactured in the US, this cable is a key component for building high-speed, reliable network infrastructure.
  • 23 AWG copper conductors for reliable data transmission
  • HDPE insulation and LSZH jacket for flame retardancy and safety
  • Category 6 performance for Gigabit Ethernet (1000 Base-T)
  • ETL verified to TIA-568.2-D Category 6 standard
  • 1000 ft. (305m) reel in a box for easy installation

Specifications

Application
Indoor
Color
White
Conductor Material
Copper
Connection Type
UTP
Construction
U/UTP
Jacket Material
LSZH Material
Length
1000
Material
Copper, HDPE, LSZH
Number of Conductors
4
Outside Diameter
NA In.
Series
TX6000
Size
23 AWG
Temperature Rating
NA F
Type
Bulk Copper Cable
Type
Copper Cable
Voltage Rating
NA V
Voltage Rating
NA V V
Package Dimensions (L x W x H)
29.2 IN x 45.3 IN x 48.9 IN
Package Weight (Imperial)
30.62 lbs
The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel

PFC6X04WH-CEG

The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel
The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE jacket. The white, LSZH (IEC 60332-3, EuroClass Cca-s1a,d1,a1) cable is supplied 305 meters (1,000 feet) to a reel.

PUY6AV04WH-EG

The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE jacket. The white, LSZH (IEC 60332-3, EuroClass Cca-s1a,d1,a1) cable is supplied 305 meters (1,000 feet) to a reel.
The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.

PFR6C04WH-UG

The TX6 Cat 6 F/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel.
Enhanced copper cable, category 5e UTP, plenum (CMP), 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, white.

PUP5504WH-UY

Enhanced copper cable, category 5e UTP, plenum (CMP), 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, white.
Copper cable, premium category 6 UTP, riser (CMR), 4-pair, conductors are 23 AWG construction with HDPE insulation, twisted in pairs, separated by an integrated pair divider and protected by a flame-retardant PVC jacket, white.

PUR6504WH-UY

Copper cable, premium category 6 UTP, riser (CMR), 4-pair, conductors are 23 AWG construction with HDPE insulation, twisted in pairs, separated by an integrated pair divider and protected by a flame-retardant PVC jacket, white.
Cat 6A Advanced MaTriX 4-pair 23 AWG copper cable, U/UTP, LSZH (Low Smoke Zero Halogen, IEC60332-1 and 60332-3) rated, White, Euro pallet, 1000ft/305m.

PUL6AM04WH-CEG

Cat 6A Advanced MaTriX 4-pair 23 AWG copper cable, U/UTP, LSZH (Low Smoke Zero Halogen, IEC60332-1 and 60332-3) rated, White, Euro pallet, 1000ft/305m.
The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 500m on a reel.

PUL6004WH-EDY

The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), White jacket. Packaged 500m on a reel.
The TX7000 Cat 7 S/FTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are individually shielded, twisted in pairs and covered by an overall braided shield and a HDPE flame retardant (LSZH), White jacket. Packaged 1640FT/500M on a reel

PSL7004WH-CED

The TX7000 Cat 7 S/FTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are individually shielded, twisted in pairs and covered by an overall braided shield and a HDPE flame retardant (LSZH), White jacket. Packaged 1640FT/500M on a reel
The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m in an easy payout carton.

PUR6C04WH-F

The TX6 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m in an easy payout carton.
Shielded copper cable, category 5e F/UTP, plenum (CMP), conductors are 24 AWG construction with FEP insulation, twisted in pairs, surrounded by an overall polyester aluminum foil with stranded copper drain wire and protected by a low smoke flame-retardant PVC jacket, white.

PFP5504WH-UY

Shielded copper cable, category 5e F/UTP, plenum (CMP), conductors are 24 AWG construction with FEP insulation, twisted in pairs, surrounded by an overall polyester aluminum foil with stranded copper drain wire and protected by a low smoke flame-retardant PVC jacket, white.
The TX6A Cat 6A U/UTP LSZH copper cable is constructed of 26 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs, separated by a cross divider and covered by a HDPE flame retardant (LSZH), White jacket. Packaged 1000ft/305m on a reel

PUL6ASD04WH-EG

The TX6A Cat 6A U/UTP LSZH copper cable is constructed of 26 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs, separated by a cross divider and covered by a HDPE flame retardant (LSZH), White jacket. Packaged 1000ft/305m on a reel
The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel in a box.

PUR6004WH-UY

The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel in a box.

Frequently Asked Questions

What are the electrical performance standards?

The cable exceeds ISO 11801 Class E and ANSI/TIA-568-2.D standards at swept frequencies up to 250 MHz.

What type of insulation is used?

The conductors are insulated with HDPE (High-Density Polyethylene).

What is the maximum operating voltage?

The maximum operating voltage for the cable is 80V.

What is the operating temperature range?

The cable operates within a temperature range of -20°C to 60°C (-4°F to 140°F).

What is the cable diameter?

The cable diameter is 5.7 mm (0.224 in.).

Is the cable compatible with PoE applications?

Yes, the cable meets IEEE 802.3af and IEEE 802.3at standards for PoE applications.

What is the temperature rating for installation?

The installation temperature rating is 0°C to 50°C (32°F to 122°F).

What is the maximum installation tension?

The maximum installation tension for the cable is 110 N (25 lbf).

What is the flame rating of the cable?

The cable meets IEC 60332-1, IEC 60332-3-22, and other flame rating standards.

What packaging options are available?

The cable is available in 305m (1000 ft.) on a reel-in-a-box or 500m (1640 ft.) on a reel.
