Panduit PFP6C04BL-UG - The TX6 Cat 6 F/UTP Plenum copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a flame retardant PVC (CMP), Black jacket. Packaged 1000 ft./305m on a reel.
Panduit

PFP6C04BL-UG

UPC: 613056571174

Documents & Media
BrochureSpecification Sheet

Contact for Pricing

Minimum Qty: 20000

Multiplier: 1000

*Contact for lower quantities*

Overview

The Panduit TX6 Cat 6 F/UTP Plenum copper cable (SKU: PFP6C04BL-UG) is engineered for high-speed data transmission in demanding plenum environments. This cable features 23 AWG copper conductors with FEP/polyolefin insulation, ensuring robust electrical performance. Each pair of conductors is twisted and separated by a cross divider, minimizing crosstalk and signal interference. The cable is further protected by an overall metallic shield, providing enhanced resistance to electromagnetic interference (EMI). The jacket is constructed from flame-retardant PVC (CMP-rated), making it suitable for use in air-handling spaces as per building codes. This F/UTP (Foiled/Unshielded Twisted Pair) Category 6 cable supports data rates up to 1 Gigabit Ethernet and is specified to 350MHz, tested to 500MHz, and ETL verified to the TIA-568.2-D Category 6 standard. The black jacket color facilitates easy identification and cable management. Supplied on a 1000 ft. (305m) reel, this cable is designed for efficient installation and reliable network infrastructure. Its construction ensures balanced electrical performance across the entire frequency range, crucial for voice, video, and data applications. The use of a cross divider contributes to improved electrical characteristics and overall cable integrity. Manufactured in the USA, this Panduit cable is a dependable choice for network backbone and horizontal cabling where plenum-rated performance is essential.
  • 23 AWG copper conductors with FEP/polyolefin insulation
  • F/UTP (Foiled/Unshielded Twisted Pair) construction with overall metallic shield
  • Flame-retardant PVC (CMP) black jacket for plenum environments
  • Category 6 performance, specified to 350MHz, tested to 500MHz
  • 1000 ft. (305m) reel for efficient installation

Specifications

Conductor Material
Copper
Construction
F/UTP
Jacket Material
PVC
Number Of Conductors
4
Outside Diameter
NA In.
Temperature Rating
NA F
Type
Bulk Copper Cable
Voltage Rating
NA V
Package Dimensions (L x W x H)
44 IN x 48 IN x 51 IN
Package Weight (Imperial)
950 lbs
