Panduit PFO6X04BL-CEG The TX6A Cat 6A shielded copper cable is a F/UTP Outside Plant (OSP) cable. The cable…
UPC: 613056319493
Documents & Media
Contact for Pricing
Minimum Qty: 6
Multiplier: 6
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Category 6A OSP cable meeting ANSI/TIA-568.2-D component standard
- 23 AWG solid copper conductors with polyolefin insulation
- Gel-filled construction prevents moisture migration in wet/underground applications
- Overall foil shield for EMI protection and minimized alien crosstalk
- UV-resistant and abrasion-resistant black polyethylene (PE) jacket
Specifications
Color | Black |
Color | Blue |
Conductor Material | Copper |
Connection Type | F/UTP shielded |
Construction | F/UTP |
Insulation Material | High-Density Polyethylene |
Jacket Material | High-Density Polyethylene |
Material | Copper, Polyethylene |
Number of Conductors | 4 |
Outside Diameter | 0.32 In. |
Resistance | UV-Resistant |
Series | TX6A |
Size | 23 AWG |
Standard | Exceeds ISO 11801 Class Ea and ANSI/TIA568-C.2 Category 6A standards ; Standards compliance: ISO 11801 Class Ea, IEC 61156-5 Category 6A, ANSI/TIA-568-C.2 Category 6A, IEC 60794-1-2F5 Method B Water Penetration Requirement Poe Compliance: Meets IEEE 802.3a |
Temperature Rating | 176 F |
Type | Copper Cable |
Voltage Rating | 80 V |
Package Dimensions (L x W x H) | 15.75 IN x 15.75 IN x 12.6 IN |
Package Weight (Imperial) | 84.67 lbs |
PUO6C04BL-CEG
The TX6 U/UTP Outside Plant (OSP) Copper Cable is constructed of 23 AWG copper conductors with PE insulation. The cable has a gel-filled construction to prevent moisture migration in underground and wet applications. The conductors are twisted in pairs and covered by a UV-resistant and abrasion-resistant HDPE flame-retardant jacket. This cable is for duct and conduit installations only.
PUL6004GR-EY
Enhanced Category 6, low smoke zero halogen (LSZH), 4-pair, U/UTP copper cable. Copper conductors are 23 AWG construction with HDPE insulation. Conductors are twisted in pairs, separated by an integrated pair divider, and protected by an LSZH (IEC 60332-1) jacket, Green.
PUL6004IG-EY
The TX6000 Cat 6 U/UTP LSZH copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant HDPE (LSZH), Gray jacket. Packaged 1000 ft./305m on a reel in a box.
PSW7004WH-HED
The TX7000 Category 7 copper cable is a shielded S/FTP copper cable. The copper conductors are twisted in pairs, covered by a foil shield within an overall braided shield and a HDPE flame-retardant jacket. The white, LSZH (IEC 60332-3, EuroClass B2ca-s1a,d1,a1) cable is supplied 500 meters (1,640 feet) to a reel.
PFC6X04WH-CEG
The TX6A Cat 6A F/UTP CM copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs, separated by a cross divider and covered by an overall metallic shield and a PVC flame retardant, White jacket. Packaged 1000ft/305m on a reel
PUY6AV04WH-EG
The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE jacket. The white, LSZH (IEC 60332-3, EuroClass Cca-s1a,d1,a1) cable is supplied 305 meters (1,000 feet) to a reel.
PUR6AV04BU-G
The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant PVC jacket. The blue, riser (CMR) cable is supplied 1,000 feet (305 meters) to a reel.
Frequently Asked Questions
What is the maximum operating voltage for this cable?
The maximum operating voltage for the cable is 80V.
Is the TX6A OSP cable compliant with PoE standards?
Yes, it meets IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt for various PoE applications.
What are the installation requirements for this cable?
This product is to be used in duct and conduit installations only. It is not to be used in aerial or direct bury applications.
What are the operating and installation temperature ranges?
The operating temperature range is -40ºF to 176ºF (-40ºC to 80ºC). During installation, the temperature range is 32ºF to 122ºF (0ºC to 50ºC).
What transmission speeds does this cable support?
It supports 10GBASE-T Ethernet, 1000BASE-T Gigabit Ethernet, and 10/100BASE-T Ethernet applications.
What standards does the TX6A OSP cable meet?
The cable meets ISO 11801 Class EA, IEC 61156-5 Category 6A, and ANSI/TIA-568.2-D Category 6A standards. It also meets IEC 60794-1-2F5 for water penetration.
What transmission speeds does this cable support?
It supports 10GBASE-T Ethernet, 1000BASE-T Gigabit Ethernet, and 10/100BASE-T Ethernet applications.
What is the maximum operating voltage for this cable?
The maximum operating voltage for the cable is 80V.
What standards does the TX6A OSP cable meet?
The cable meets ISO 11801 Class EA, IEC 61156-5 Category 6A, and ANSI/TIA-568.2-D Category 6A standards. It also meets IEC 60794-1-2F5 for water penetration.
Is the TX6A OSP cable compliant with PoE standards?
Yes, it meets IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt for various PoE applications.
