Overview
- 32A continuous current rating at 400V three-phase
- 42 total outlets: 30 IEC C13 and 12 IEC C19
- IEC 60309 3P+N+E 6h input plug for industrial compatibility
- IP44-rated enclosure for splash and particulate protection
- 10-foot (3m) power cord for flexible installation
Specifications
Frequency Rating, Maximum | 230 V |
Frequency Rating, Minimum | 230 V |
Material | Metal |
Mounting | Vertical |
Phase | 3 |
Standard | CE, UKCA, ROHS, REACH, China ROHS |
Type | PDU |
Width | 2.2 in |
Width | 55.88 mm |
Package Dimensions (L x W x H) | 78 IN x 8 IN x 5 IN |
Package Dimensions (L x W x H) | 198.12 cm x 20.32 cm x 12.7 cm |
Package Weight (Imperial) | 24.0000 L |
Package Weight (Metric) | 10.8864 kg |
SP279
Wall Plate Screw, #6-32 size, Oval head, 1 in. length, White head color, Slotted drive type, Steel, Zinc Plated finish, 100 per pack
B118A
One-Gang Nail-On New Work Outlet Box, Volume 18 Cubic Inches, Length 3-3/4 Inches, Width 2-1/4 Inches, Depth 2-7/8 Inches, Color Blue, Material PVC, Mounting Means Captive Nails
B232ACP
Two-Gang Nail-On New Work Outlet Box, Volume 32 Cubic Inches, Length 3-3/4 Inches, Width 4 Inches, Depth 3 Inches, Color Blue, Material PVC, Mounting Means Captive Nails
A414
One-Gang Box Cover, Volume 8.1 Cubic Inches, 4 Inches Square, Raised 1-1/4 Inch, Color Blue, Material Non-Metallic
SC100RR
One-Gang Low-Voltage Old Work Bracket, Length 4.32 Inches, Width 2.52 Inches, Depth 1.66 Inches, Color Orange, Material Non-Metallic
A410R-CAR
One-Gang Box Cover, Volume 3.5 Cubic Inches, 4 Inches Square, Raised 1/2 Inch, Color Blue, Material Non-Metallic
IPLMD350-6
The Polaris IPLMD350-6 Multi-Tap Mountable Dual-Sided Entry Connector features 6 ports sized for 350 MCM - 6 AWG wires. Mounting holes on either side of the connector allow for direct mounting to troughs, panels or wireways with 1/4†bolts. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
![Quick Disconnects, Receptacle, 22 – 18 AWG Wire Size, .26 – .96 mm² Wire Size, 509 – 1900 CMA Wire Size, Mating Tab Width 2.79 mm [.11 in], FASTON 110](/_next/image?url=https%3A%2F%2Fwww.te.com%2Fcontent%2Fdam%2Fte-com%2Fcatalog%2Fpart%2F000%2F610%2F481%2F61048-1-t1.jpg%2Fjcr%3Acontent%2Frenditions%2Fproduct-high-res.png&w=3840&q=75)
Frequently Asked Questions
What type of PDU is P42B11M?
The P42B11M is a Basic PDU, a non-intelligent power distribution unit providing reliable power for low-cost solutions.
What are the input power specifications for P42B11M?
The P42B11M requires 200-240VAC, 1-Phase input at 32A, using an IEC 60309 2P+E 6h 32A plug type, providing 7.4 kVA.
What outlets does the P42B11M PDU provide?
The P42B11M PDU is equipped with 30 IEC C13 outlets and 12 IEC C19 outlets.
What are the physical dimensions of the P42B11M PDU?
The P42B11M PDU measures 1750.0 mm in length, 52.2 mm in width, and 53.0 mm in depth at the outlet position.
What is the form factor of the P42B11M PDU?
The P42B11M PDU features a 0U MID form factor.
What is the maximum operating temperature for this PDU?
The PDU can withstand 140°F (60°C) at full load due to its premium components.
What is the warranty for the P42B11M PDU?
The P42B11M PDU includes a 3-year standard warranty, with an option to extend it to 5 years.
Can dual locking power cords be used with P42B11M?
Yes, dual locking power cords are available and compatible for use with all Panduit power distribution units.
Does the P42B11M PDU offer high outlet density?
Yes, the P42B11M PDU incorporates a unique outlet design to achieve high outlet density.
Are there different color options for the P42B11M PDU?
Yes, Panduit offers a variety of colored PDU chassis, power cords, and cable ties.
How to Install and Configure a Panduit G5 PDU
This guide provides step-by-step instructions for installing Panduit G5 Metered, Switched, and Metered & Switched Power Distribution Units (PDUs) into a datacenter rack, including mounting, grounding, power connection, and initial configuration.
Estimated time: 45m
Tools needed:
Phillips screwdriver, Torx screwdriver
Supplies needed:
Mounting hardware, Ground bonding cable, Tie wraps, Cage nuts
- Review Safety Information and Prepare
Before beginning, ensure you are qualified personnel knowledgeable about AC power products. Read all safety information, including warnings about high leakage current and lethal voltages. Ensure the installation environment is temperature and humidity controlled, free of contaminants, and within 0°C to 60°C (32°F to 140°F) ambient temperature. Verify the PDU is intended for Information Technology Equipment (ITE) loads with linear/PFC input current.
- Mount the PDU in the Rack
Install the PDU into the datacenter rack using the provided mounting hardware. For vertical PDUs, align and install mounting buttons into the PDU's screw holes (either opposite outlets for center-facing, or on the sides for back/front-facing), then insert the buttons into the keyhole slots on the rack's PDU mounting bracket. For 1U/2U PDUs, install cage nuts at the desired U location, then screw the mounting bracket ears into the RETMA rail surface. Ensure the PDU is securely attached.
- Ground the PDU
Connect a ground bonding cable from the external ground bonding point on the PDU chassis to a known earthed reference terminal in the building or to the rack's grounding strip/bus bar. Ensure the bonding conductor meets the minimum AWG requirements (e.g., 12 AWG for up to 32A) and use the appropriate screw size (e.g., 5mm for over 16A to 40A).
- Attach the Input Cord to Universal Input PDUs (if applicable)
For Universal Input PDUs, ensure the facility side connector is disconnected. Open the input cord connector latches on the PDU, insert the input cord plug, and then close the latches to securely lock the input cord into the connector. Ensure the uPDU interconnect is fully secured to the mating PDU side connector. This step must be performed by a skilled person with the facility side connector disconnected.
- Connect the PDU to a Power Source
WARNING: Ensure the feed circuit breaker is OFF before connecting power. Verify all circuit breakers on the PDU are set to ON. Connect the PDU's input power cord to a grounded (earthed) electrical outlet on an appropriately rated, dedicated branch circuit, protected by a circuit breaker matching the PDU input plug type. Refer to the PDU label for input ratings. Once connected, turn the feed circuit breaker ON. The OLED screen will display a status bar during boot-up, then the Main Menu.
- Configure Universal Input PDU Input Type (if applicable)
For Universal Input PDUs, connect to the PDU's Web interface (refer to the User Manual for access instructions). Navigate to the 'System Management' page under settings, then select 'Set Input Cord' under actions. Choose the correct cord type from the pull-down menu based on your installed input cord part number. Select 'Save' to apply the changes; the PDU will reset.
- Secure Connected Power Cords (Optional)
To prevent accidental disconnects, utilize the integrated cord retention feature on most C13 and C19 outlets. Plug in the power cord, then use the provided tie wraps to slide an end into the notch next to the outlet and wrap it around the cord, securing it firmly. Alternatively, use optional locking power cords on compatible outlets.
