Contact for Pricing
Overview
- 30 C13 and 6 C19 outlets for versatile equipment compatibility
- 16 amp, 400V three-phase power with IEC 60309 3P+N+E 6h 16A input plug
- Monitored and switched per-outlet control for remote power management
- 10-foot (3m) power cord with IP44-rated input plug for secure connections
- Compact black housing fits standard 19-inch racks
Specifications
Package Dimensions (L x W x H) | 78 IN x 8.2 IN x 4.6 IN |
Package Dimensions (L x W x H) | 198.12 cm x 20.828 cm x 11.684 cm |
Package Weight (Imperial) | 17.2000 L |
Package Weight (Metric) | 7.8019 kg |
P12B19M
This Panduit G5 Basic PDU features (12) 5-20R outlets. It is a 20 amp, 120 V, single phase PDU with a NEMA 5-20P input plug and a 10 foot (3m) power cord. The PDU is black.
P36F13G
The Panduit™ G6 Monitored Per Outlet PDU features (24) C13 and (12) C19 outlets. It is a 32 amp, 400 V, three phase PDU with an IEC 60309 3P+N+E 6h 32A (IP44) input plug and a 10 foot (3m) power cord. The PDU is black.
P36G16G
The Panduit™ G6 Monitored & Switched per Outlet PDU features (24) C13 and (12) C19 outlets. It is a 32 amp, 400 V, three phase PDU with an IEC 60309 3P+N+E 6h 32A (IP44) input plug and a 10 foot (3m) power cord. The PDU is black.
Frequently Asked Questions
What is the standard warranty for Panduit PDUs?
Panduit PDUs come with a 3-year standard warranty, with an option for a 5-year extended warranty.
What is the maximum operating temperature for PDUs?
Panduit PDUs are designed to operate reliably at full load in temperatures up to 140°F (60°C).
Do Panduit PDUs support hot-swappable components?
Yes, they feature a hot-swappable controller with a large OLED display, allowing removal without affecting outlet status.
What type of Ethernet connection is available?
Panduit PDUs include a 1 GB on-board Ethernet connection that auto negotiates to 1GB network switches.
What can Panduit PDUs monitor in real-time?
They provide real-time monitoring of power, environmental conditions, and cabinet security.
Are Panduit PDUs compatible with Cisco Nexus Dashboard?
Yes, intelligent Panduit PDUs integrate with Cisco Nexus Dashboard software for energy savings and sustainability insights.
How are Panduit PDUs mounted in a rack?
Panduit PDUs feature tool-less mounting, allowing effortless installation into a rack using a convenient button slot.
What types of outlets do combination outlets support?
Combination outlets offer flexibility, allowing each outlet to be used as a C21, C19, C15, or C13.
What circuit protection do Panduit PDUs offer?
PDUs are equipped with built-in magnetic hydraulic circuit breakers, providing robust defense against short circuits and overloads.
What monitoring capabilities does the MSPO series offer?
The Monitored Switched Per Outlet (MSPO) series provides intelligent power monitoring at input and individual outlet levels, plus environmental monitoring.
How to Install and Configure the Panduit G6 PDU
This guide provides step-by-step instructions for physically installing a Panduit G6 Power Distribution Unit (PDU) in a datacenter rack, connecting its input power, and performing initial configuration via the web interface.
Tools needed:
Phillips screwdriver, Torx screwdriver
Supplies needed:
Mounting buttons, PDU mounting bracket, Input power cord, Ground bonding cable, Tie wraps, Star washer, Grounding strip or bus bar, Appropriately rated branch circuit breaker, Network cable
- Mount the PDU in the Rack
Align and install the mounting buttons with the screw holes on the PDU face opposite the outlets, or on the sides of the PDU, depending on your desired mounting orientation (outlets facing center, back, or front of the rack). Then, install the PDU by inserting the mounting buttons into the keyhole slots on the PDU mounting bracket in the rack.
- Attach the Input Power Cord to the PDU
Open the input cord connector latches on the PDU. Insert the facility-side input cord plug firmly into the universal input connector. Close the input cord connector latches on the PDU to securely lock the input cord into place.
- Connect the Ground Bonding Cable
WARNING: Ensure a reliable grounded (earthed) connection before proceeding. Connect a ground bonding cable from the external ground bonding point on the PDU chassis to a known earthed reference terminal in the building, a grounding strip, or a grounding bus bar in the rack. Use the provided external earthing screw with a star washer for supplementary Earth bonding to the rack metalwork.
- Connect the PDU to a Power Source
WARNING: Ensure all circuit breakers are in the OFF position before connecting input power. Turn OFF the feed circuit breaker for the dedicated branch circuit. Verify that all circuit breakers on the PDU are set to ON. Connect the PDU's input power cord to an appropriately rated and grounded (earthed) branch circuit outlet. Refer to the PDU label for input ratings. Finally, turn ON the feed circuit breaker. The OLED screen (on units with display) will display a status bar during loading, then the Main Menu.
- Configure Universal Input PDU Input Type via Web Interface
Access the PDU's Web interface (refer to the User Manual for connection instructions). Navigate to the 'System Management' page under 'Settings'. Select 'Set Input Cord' under 'Actions'. From the dropdown, select the correct input cord type that matches your installed facility-side cord. WARNING: If the incorrect input cord is selected, the PDU may meter data incorrectly and show an incorrect power rating. Select 'Save' to apply the changes; the PDU will reset.
- Secure Power Cords to Outlets (Optional)
For connected IT equipment power cords, utilize the integrated cord retention feature on most C13 and C19 outlets. Plug in the power cord, then slide a provided tie wrap into the notch next to the outlet and wrap it around the cord. Secure the tie wrap to eliminate accidental disconnects. Alternatively, use optional locking power cords for enhanced security.
- Perform Additional Configuration for Dual-Rated PDUs (If Applicable)
If you have a dual-rated PDU, an additional Command Line Interface (CLI) configuration step is required to enable the Web interface to report the correct power capacity. Refer to the 'CLI Commands' section in the User Manual for detailed instructions on this specific configuration.
