Contact for Pricing
Overview
- Factory-terminated #10 AWG (6mm²) copper jumper for immediate installation
- 90° bent lug on grounding strip side enables high-density grounding (1 ground point per RU)
- Includes antioxidant compound (0.16 oz / 5cc) and thread-forming screws for secure connections
- Complies with US and international grounding standards for safety and reliability
- Designed for seamless integration with PanZone Multi-Purpose Wall and In-Ceiling Enclosures
Specifications
Application | Telecom/Data Center |
Color | Green;Yellow |
Depth | NA In. |
Series | PanZone Multi-Purpose |
Type | Multi-Purpose Enclosure Grounding Kit |
Width | 13.25 In. |
Package Dimensions (L x W x H) | 8 IN x 5.1 IN x 1 IN |
Package Weight (Imperial) | 2 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the load capacity of the enclosures?
All enclosures have a load capacity of 35 lbs (16 kg).
What is the depth of the enclosures?
All enclosures have a depth of 4.05 inches.
How can the enclosure be mounted?
The enclosure can be mounted either recessed in-wall or on-wall.
Are there cable knockouts in the enclosure?
Yes, the enclosure includes cable knockout openings for easier cable routing and installation.
What is the height of the 14-inch enclosure?
The 14-inch enclosure has a height of 14.25 inches.
What is the width of the 28-inch enclosure?
The 28-inch enclosure has a width of 14.25 inches.
What materials are used in the enclosure construction?
The enclosure is constructed of 18 gauge steel with a white powder coating.
What is the purpose of the grounding kit?
The grounding kit properly bonds the door to the base to protect network equipment and maximize uptime.
What types of equipment can the enclosure house?
The enclosure can house AV or ONT devices, copper connections, and fiber connections.
What accessories are available for the enclosure?
Available accessories include device shelves, brackets, and fiber cassette brackets.
How to Install the Multi-Purpose Wall Enclosure
This guide provides step-by-step instructions for installing the Multi-Purpose Wall Enclosure, including mounting, wiring, and initial setup.
Estimated time: 1h
Tools needed:
Screwdriver, T25 Torx bit, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Bonding jumper (MSGK)
- Mount the enclosure
Align the enclosure with the wall studs and push the mounting tabs out to 90°. Secure the enclosure using a minimum of #8 wood screws with at least 3/4" penetration into the wood studs.
- Install the mud guard
Attach the mud guard to the enclosure prior to drywall installation to protect the interior from dust and debris.
- Install the front cover and trim plates
Align the front cover with the threaded holes of the enclosure and secure it using (2) M5 screws with a T25 Torx bit. Repeat this process for the top and bottom trim plates.
- Connect the bonding jumper
Install one end of the bonding jumper (MSGK) on the grounding lug inside the enclosure and secure it with the provided M5 serrated hex nut. Connect the opposite end to the grounding lug on the front cover.
- Ground the enclosure
Run a grounding cable from the Telecommunications Grounding Busbar (TGB) to the specified M5 earthing stud on the enclosure base. Ensure the grounding conductor matches or exceeds the wire gauge for power delivery.
