Contact for Pricing
Minimum Qty: 160
Multiplier: 160
*Contact for lower quantities*
Overview
- Power rated for applications up to 600 V
- Two-piece latching raceway with cover
- Pre-punched mounting holes for fast installation
- Factory-applied adhesive backing for rapid mounting
- 8 feet in length, 0.75" wide x 0.41" deep, Electric Ivory finish
Specifications
Application | Pan-Way ® LD Surface Raceways are Designed to Provide Easy and Economical Solutions For Routing any Low Voltage Cable Along Smooth and Clean Perimeter Walls, Baseboards or Ceilings. This Raceway is a Perfect Solution for Schools, Hospitals, Offices, Homes |
Application | Pan-Way LD Surface Raceways are Designed to Provide Easy and Economical Solutions For Routing any Low Voltage Cable Along Smooth and Clean Perimeter Walls, Baseboards or Ceilings. This Raceway is a Perfect Solution for Schools, Hospitals, Offices, Homes |
Color | Electric Ivory |
Color* | Electric Ivory |
Length | NA in |
Material | Polyvinyl Chloride (PVC) |
Material | Poly |
Mounting Type | Adhesive Backing + Pre-punched Mounting Holes |
Mounting Type | Surface-mounted with adhesive backing and pre-punched mounting holes |
Mounting Type | Adhesive |
Mounting Type | Surface Mount with adhesive backing |
Mounting Type | Adhesive backing with pre-punched mounting holes |
Series | LDPH3 |
Series | LDPH |
Size | 0.75 inches wide by 0.41 inches deep |
Size | 0.75" W x 0.41" D x 8' L |
Size | 0.75" x 0.41" x 8' |
Size | 8 ft L 0.75 in W x 0.41 in D |
Standard | Ul94V-0, Ft4, Meets TIA/EIA Standards, UL5A Listed, UL Compliant. |
Standard | UL94V-0, FT4, Meets TIA/EIA Standards, UL5A Listed, UL Compliant |
Type | Power Rated Channel |
Type | Single Channel Surface Raceway |
Voltage Rating | 600 V |
Width | 0.77 in |
Width | 19.558 mm |
Package Dimensions (L x W x H) | 90 IN x 2.4 IN x 0.2 IN |
Package Weight (Imperial) | 0.644 lbs |
LDPH5EI8-A
The LDPH5 power rated Surface Raceway is a two-piece latching raceway with cover suitable for applications up to 600 V. It features pre-punched mounting holes and factory-applied adhesive backing for fast mounting. It is 8 feet in length and is 1.02 inches wide by 0.55 inches deep. It meets TIA/EIA Standards, is UL5A Listed, and is UL Compliant. It is Electric Ivory.
Frequently Asked Questions
What is the voltage rating of the CRFX5IW-X?
The CRFX5IW-X is power rated up to 600 volts.
What is the operating temperature range?
The operating and storage temperature range is 0°C to 50°C.
What materials are used in the raceway?
The raceway is made of rigid PVC, which is impact resistant.
What sizes are available for the raceway?
The raceway is available in sizes LDPH3, LDPH5, and LDPH10.
What types of cables can be used with the raceway?
The raceway can accommodate power, low voltage, and fiber optic cables.
Is the raceway tamper resistant?
Yes, the raceway is highly tamper resistant to prevent unauthorized access.
What types of junction boxes are compatible?
Compatible junction boxes include single and double gang options in various configurations.
