Contact for Pricing
Minimum Qty: 20
Multiplier: 20
*Contact for lower quantities*
Overview
- 2mm thick steel channel for vertical cable management
- Hinge design enables tool-free cable insertion and removal
- Compatible with 19-inch and 23-inch equipment racks
- Supports high-density cable installations with organized pathways
- Durable construction for long-term reliability in demanding environments
Specifications
Application | Data Centers and Telco Central Offices |
Height | 2 In. |
Material | Polycarbonate |
Standard | RoHS Compliant, UL Listed to 2024 Optical Fiber Cable Routing Assemblies Compliant with the applicable tests in Telcordia GR-63-CORE Network Equipment Building Systems Level 3 |
Type | Channel |
Width | 2.17 In. |
Package Dimensions (L x W x H) | 78.7 IN x 2 IN x 2 IN |
Package Weight (Imperial) | 2.42 lbs |
FRCR6LBL-X
The FiberRunner 6x4 Cable Retainer holds cable in the channel when cover is not used. It is 150mm x 100mm. This includes 10 per package.
FR12X4BL2
Used to carry the cables horizontally throughout the system. Accepts cable retainers FRCR12BL or hinged cover FRHC12BL2. Use QuikLock Coupler FRBC12X4BL to attach channel and/or fittings.
PWB4X12BL
The 4" height x 12" width wire basket is available in a black powdered coated finish. The wire basket can be used in many applications to route cable to the needed location. It s design enable users to have to cut less wires on a basket with improves risk mitigation.
PWB6X6BL
The 6" height x 6" width wire basket is available in a black powdered coated finish. The wire basket can be used in many applications to route cable to the needed location. It s design enable users to have to cut less wires on a basket with improves risk mitigation.
PWB2X24BL
The 2" height x 24" width wire basket is available in a black powdered coated finish. The wire basket can be used in many applications to route cable to the needed location. It s design enable users to have to cut less wires on a basket with improves risk mitigation.
PWB2X18EZ
The 2" height x 18" width wire basket is available in an electro zinc finish. The wire basket can be used in many applications to route cable to the needed location. It s design enable users to have to cut less wires on a basket with improves risk mitigation.
PWB6X8BL
The 6" height x 8" width wire basket is available in a black powdered coated finish. The wire basket can be used in many applications to route cable to the needed location. It s design enable users to have to cut less wires on a basket with improves risk mitigation.
PWB2X18BL
The 2" height x 18" width wire basket is available in a black powdered coated finish. The wire basket can be used in many applications to route cable to the needed location. It s design enable users to have to cut less wires on a basket with improves risk mitigation.Frequently Asked Questions
What is the purpose of the FiberRunner 2x2 system?
The FiberRunner 2x2 routing system segregates, routes, and protects fiber optic and high performance copper cabling.
What bend radius do fittings maintain?
All fittings maintain a minimum 2-inch bend radius to protect against signal loss from excessive cable bends.
What colors are available for the system?
The FiberRunner 2x2 Routing System components are available in yellow and black.
What structures can the system attach to?
The system can attach to ladder rack, threaded rod, auxiliary framing, strut, equipment racks, and raised floor pedestals.
What materials are used for the system?
The channel is made of Rigid PVC, and the fittings are made of PC/ABS.
What is the flammability rating?
The system has a flammability rating of 94V-0.
What are the system's approvals?
The system is UL Listed to 2024 Optical Fiber Cable Routing Assemblies.
How fast is system installation?
QuikLock™ Couplers allow for fast installation, requiring no tools or bolts and making a secure connection in less than five seconds.
How is system maintenance facilitated?
Hinged channel covers, hinged door vertical tees, and solid fitting covers provide fast and easy access for future cabling moves, adds, and changes.
Where can the FiberRunner 2x2 system be used?
It is suited for data centers, Telco Central Offices, and can be deployed over racks or in approved underfloor applications.
How to Install the H2X2 Fiber Runner 2x2 Cable Routing System
This guide provides step-by-step instructions for installing the H2X2 Fiber Runner 2x2 cable routing system, ensuring proper mounting and connection.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the Fiber Runner
Secure the H2X2 Fiber Runner to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the fittings
Attach the appropriate fittings to the Fiber Runner by aligning the couplers and pressing them together until they click into place. Ensure a secure connection.
- Verify connections
Use a multimeter to check the continuity of the connections made. Ensure all connections are secure and functioning properly before proceeding.
