Panduit FZURLENENYNM009 - OM4 24 fiber, Interconnect, LSZH, 24F MPO Female to 24F MPO Female, Method B, Optimized IL, 9 m, Aqua
Panduit

FZURLENENYNM009

UPC: 613056190047

Documents & Media
Technical DrawingFull Engineering DrawingSpecification Sheet

Contact for Pricing

Overview

This Panduit FZURLENENYNM009 is a high-density OM4 fiber optic interconnect cable designed for efficient data transmission in demanding network environments. Featuring 24 fibers, it utilizes MPO (Multi-fiber Push On) connectors on both ends, configured as 24F Female to 24F Female. This specific configuration employs Method B polarity, crucial for ensuring correct signal path mapping in duplex applications. The cable is constructed with LSZH (Low Smoke Zero Halogen) jacketing, providing enhanced safety by minimizing smoke and toxic gas emissions during a fire, making it suitable for installation in plenum spaces and other sensitive areas. Engineered for optimized insertion loss (IL), this cable ensures signal integrity and reliable performance for high-speed data networks, including 10/40/100 Gigabit Ethernet and beyond. The aqua color coding clearly identifies it as an OM4 multimode fiber cable. With a length of 9 meters, it offers flexibility for various rack and cabinet configurations. Manufacturer: Panduit. SKU: FZURLENENYNM009. UNSPSC Code: 26121650. Country of Origin: US.
  • OM4 Multimode Fiber for high-speed data transmission
  • 24 Fiber MPO Female to 24 Fiber MPO Female connectors
  • Method B polarity for proper signal mapping
  • LSZH (Low Smoke Zero Halogen) jacketing for safety
  • Optimized Insertion Loss (IL) for signal integrity
  • Aqua color for easy identification
  • 9-meter cable length
  • Manufacturer: Panduit

Specifications

Application
OM4
Color
Aqua
Connection Type
MPO Female to MPO Female
Connector 1 Type*
MPO Female
Connector 2 Type*
MPO Female
Fiber Compatibility*
OM4 50/125um
Fiber Count*
24
Length
29.53 FT
Material
LSZH
Poles
24F
Size
9 m
Standard
Meets or exceeds ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-5 (FOCIS-5), TIC/EIA-568-C.1, RoHS Complaint
Temperature Rating
158 F
Type
Interconnect Cable Assembly
Package Dimensions (L x W x H)
17 IN x 14 IN x 1.5 IN
Package Weight (Imperial)
0.331 lbs
