Panduit FXTYL5EL2SAM080 - OM3 12-fiber, indoor small diameter trunk cable assembly, low smoke zero halogen rated, MPO female To LC duplex, Std. IL, with pulling on eye on end A, 80 meters.
Panduit

FXTYL5EL2SAM080

UPC: 074983725779

Documents & Media
Technical DrawingFull Engineering DrawingSpecification Sheet

Contact for Pricing

Overview

Panduit FXTYL5EL2SAM080 is a high-density OM3 12-fiber indoor trunk cable assembly optimized for demanding network environments. It features a small-diameter design for efficient space utilization in conduits and racks. Constructed with Low Smoke Zero Halogen (LSZH) materials, it minimizes toxic and corrosive gas emissions during fire, meeting stringent safety standards for enclosed spaces. The assembly includes an MPO female connector on one end and LC duplex connectors on the other. The MPO connector supports high-density interconnectivity for backbone cabling and high-speed switch-to-switch connections. The LC duplex connectors, with their compact size and secure locking mechanism, are ideal for patch panel connections and server uplinks. Rated for Standard Insertion Loss (Std. IL), this assembly ensures consistent signal integrity for optical networks. The 12-fiber configuration enables parallel optics and high-bandwidth applications, supporting 10 Gigabit Ethernet and 40/100 Gigabit Ethernet with a bandwidth of 2000 MHz-km. A pulling eye integrated on end A facilitates installation and protects the cable during deployment. The 80-meter length provides ample reach for diverse data center and enterprise network layouts. Manufactured in the USA, this cable assembly adheres to strict quality control standards. Its LSZH rating makes it suitable for installations where fire safety regulations are critical, such as public buildings, transportation hubs, and educational institutions. The small diameter also enhances airflow and simplifies cable management.
  • OM3 12-fiber indoor trunk cable assembly
  • MPO female to LC duplex connectors
  • Low Smoke Zero Halogen (LSZH) rated for safety
  • 80 meters in length with pulling eye on end A
  • Standard Insertion Loss (Std. IL) for reliable performance

Specifications

Application
OM3
Color
Aqua
Color
Other
Connection
MPO Female
Fiber Compatibility*
OM3 50/125 m
Fiber Count*
12
Length
262.47 In.
Material
LSZH
Special Features
Indoor
Standard
Meets or exceeds: ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-5, (FOCIS-5), TIC/EIA-568-C.1, GR-409-CORE, ICEA S-83-596, RoHS Compliant
Temperature Rating
158 F
Type
Trunk Cable Assembly
Package Dimensions (L x W x H)
22 IN x 22 IN x 6.4 IN
Package Weight (Imperial)
11.01 lbs
