Contact for Pricing
Overview
- Includes 2m simplex standard grade LC to reference grade LC reference cables
- Includes 2m simplex standard grade SC to reference grade LC reference cables
- Includes 2m simplex standard grade LC to reference grade LC master cables
- Features 2 LC duplex adapters with zirconia ceramic split sleeves
- Comes with 2 mandrels (50/125 µm) for calibration
Specifications
Application | OM3 |
Color | Aqua |
Color | Other |
Connector 1 Type* | LC-LC Simplex |
Connector 2 Type* | SC-LC Simplex |
Fiber Compatibility* | OM3 50/125um |
Fiber Count* | 1 |
Length | 0.00 FT |
Material | Riser (OFNR) |
Standard | TIA/EIA-568-B.3 Performance Requirements 100% factory inspected endface geometry in compliance with Telcordia GR-326-CORE, Issue 3 |
Temperature Rating | NA F |
Type | Fiber Optic Patch Cord |
Package Dimensions (L x W x H) | 8.37 IN x 7.37 IN x 7.37 IN |
Package Weight (Imperial) | 1.2 lbs |
Similar Products
You May Also Be Interested In
Frequently Asked Questions
What is the maximum insertion loss for this product?
The maximum insertion loss is 0.10dB per connection for both multimode and singlemode.
Are the cables RoHS compliant?
Yes, the fiber optic reference cable assembly kits are RoHS compliant.
How are the cable assemblies inspected?
All fiber optic reference cable assembly kits and assemblies are 100% factory inspected.
What types of fiber does the FR1XS1-R1KIT support?
The FR1XS1-R1KIT supports multimode (10GIG OM3 and OM1) and singlemode (OS1/OS2) fiber types.
What connectors are included in the assembly kits?
The assembly kits include simplex and duplex LC, SC, and ST connectors.
What is the significance of the endface geometry?
The endface geometry complies with Telcordia GR-326-CORE, ensuring high performance and reliable connector performance.
What is the minimum return loss for singlemode connections?
The minimum return loss for singlemode connections is 58dB with UPC polished connectors.
What is the purpose of the hybrid reference cord variants?
Hybrid reference cord variants allow testing with different connectors, providing flexibility for legacy and current connectors.
What applications are these cable assemblies used for?
These cable assemblies are typically used for commissioning and qualification of fiber-based permanent links.
