Contact for Pricing
Minimum Qty: 3000
Multiplier: 3000
*Contact for lower quantities*
Overview
- Vibration resistant design for secure connections
- Brass construction with tin plating for conductivity
- Fully insulated red nylon housing
- Tab size: 0.187 x 0.032" (4.8 x 0.8 mm)
- Wire range: 22-18 AWG (0.5-1.0 mm²)
Specifications
Color | Red |
Connection | Funnel Entry |
Connection Type | Funnel entry barrel, Butted seam barrel |
Finish | Tinned |
Insulation | Nylon |
Material | Brass |
Material | Brass, Tin-plated, Nylon |
Mounting | 9/32 In. |
Size | 0.78" (19.8 mm) long, 0.29" (7.4 mm) wide, Tab size: 0.187 x 0.032" (4.8 x 0.8 mm) |
Standard | CSA Certified LR31212, C22.2 No.153;UL 310 Listed, UL Listed 20H3 E78522 |
Temperature Rating | 221 Degrees Fahrenheit (105 Degrees Celsius) |
Type | Disconnect |
Voltage Rating | 600 V |
Wire Size | 18 AWG |
Package Dimensions (L x W x H) | 26.1 IN x 25.4 IN x 2.4 IN |
Package Weight (Imperial) | 9.3 lbs |
