Contact for Pricing
Overview
- Part of Panduit's Universal Single Row Containment system
- Designed for 900mm wide aisles
- White finish for clean aesthetics
- Enhances thermal management and airflow control
- Manufactured in the US
Specifications
Application | Universal Single Row Containment System will be able to retrofit in a Brownfield (existing Data Center) or Greenfield (new Data Center) application that uses non-Panduit cabinets. |
Color | White |
Depth | .71 In. |
Material | Polycarbonate;Steel |
Series | Net-Contain Universal Single Row Containment |
Size | 900mm wide aisle |
Standard | RoHS Compliant |
Type | Vertical Wall Brace |
Width | 35.58 in |
Width | 903.732 mm |
Package Dimensions (L x W x H) | 39.5 IN x 6.125 IN x 3 IN |
Package Weight (Imperial) | 4.41 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the static load rating of the cabinet?
The static load rating is 3000 lbs. for the cabinet.
What is the rolling load rating of the cabinet?
The rolling load rating is 2500 lbs. for the cabinet.
What is the installation time reduction with the leveling feet?
The innovative leveling feet design reduces installation time by up to 80%.
What safety features are included in the cabinet?
The entire cabinet is fully electrically bonded, requiring no grounding whips for safety.
What are the cabinet width options available?
Cabinet widths available are 600mm, 700mm, and 800mm.
What heights are available for the cabinets?
Cabinet heights available are 42RU, 45RU, and 48RU.
Are the cabinets compatible with other Panduit products?
Yes, the cabinets are compatible with various Panduit product lines including FiberRunner®.
What are the color options for the cabinets?
The cabinets are available in black and white color options.
What is the benefit of the integral cabinet air seal?
The integral cabinet air seal improves thermal management and reduces cooling energy consumption.
How can I improve cable management in the cabinet?
Use modular snap-in fingers that align with rack spaces for cable management.
How to Install the End of Row Cap for CUSREORCPW1
This guide provides step-by-step instructions for installing the End of Row Cap for the CUSREORCPW1 containment system.
Estimated time: 30m
Tools needed:
Screwdriver, Drill
Supplies needed:
End Cap Base, End Cap Clamps, End Cap Posts, End Cap Header, End Cap Foot Covers, End Cap Foot, End Cap Shield, USRC End Cap Panel, Hardware Kit
- Attach End Cap Foot to Floor
Secure the End Cap Foot to the floor using appropriate fasteners. Ensure it is level and firmly attached.
- Install End Cap Posts
Position the End Cap Posts vertically and secure them to the End Cap Base using the provided clamps. Ensure they are straight and aligned.
- Attach End Cap Header Assembly
Connect the End Cap Header to the top of the End Cap Posts. Use the hardware kit to secure it tightly, ensuring stability.
- Install End Cap Shield
Attach the End Cap Shield to the End Cap Header. Ensure it is properly aligned and secured with the provided fasteners.
- Finalize with End Cap Panel
Install the USRC End Cap Panel onto the End Cap structure, securing it with the clamps provided in the hardware kit.
