Contact for Pricing
Overview
- Designed for 4-foot wide aisles
- Single door unit: 2134mm tall x 1422mm wide
- Compatible with Net-Access N-Type and S-Type cabinets (600mm, 700mm, 800mm)
- Easy-glide track system for smooth operation
- Enhances thermal containment and airflow management
Specifications
Color | Black |
Depth | 4.4 In. |
Standard | RoHS Compliant |
Type | Dual-Sliding Door |
Width | 56 in |
Width | 1422.4 mm |
Package Dimensions (L x W x H) | 96.25 IN x 30 IN x 70 IN |
Package Weight (Imperial) | 280 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
Can this system be used with non-Panduit cabinets?
Yes, the system is compatible with all major cabinet brands and sizes.
Is the system suitable for existing data centers?
Yes, it can retrofit in both Brownfield and Greenfield applications.
Can cabinets be easily moved in and out?
Yes, cabinets can be rolled in and out without disturbing the containment structure.
What is the height adjustment range of the system?
The system height is adjustable from 42 RU to 52 RU.
What types of containment does the system offer?
The system offers roof containment for Cold Aisle and vertical wall containment for Hot Aisle.
How is unoccupied cabinet space sealed?
Unoccupied cabinet space is sealed with full height blanking panels and tool-less blanking panels.
Does the system require moving parts?
No, this passive system contains no moving parts, enhancing energy efficiency.
What is the installation requirement for the system?
The system can be deployed on raised or slab floors without disrupting existing equipment.
What is the maximum aisle width supported?
The system supports aisle widths of 900mm, 1200mm, and 1800mm.
What materials are used for the containment system?
The system is comprised of wall beams, end-of-row frames, and sliding doors.
How to Install the C2CAC08F04IRB1 Ceiling Structure
This guide provides step-by-step instructions for installing the C2CAC08F04IRB1 ceiling structure, including mounting, wiring, and initial configuration.
Estimated time: 1h
Tools needed:
Screwdriver, Level, Wire strippers
Supplies needed:
M5 screws, Foam seal, Ceiling panels, Aisle beam, Ceiling panel stops
- Install the Aisle Beam
Secure the aisle beam to the designated mounting points using M5 screws. Ensure the beam is level before tightening.
- Attach Ceiling Panel Stops
Install the ceiling panel stops at the ends of the aisle beam using M5 screws. Ensure they are securely fastened to prevent panel movement.
- Mount Ceiling Panels
Align the ceiling panels with the aisle beam and panel stops. Secure each panel in place using the provided hardware, ensuring a tight fit.
- Apply Foam Seal
Cut the foam seal to the appropriate length and apply it along the edges of the ceiling panels to ensure a tight seal against air leakage.
- Verify Installation
Check all connections and ensure that the ceiling structure is stable and secure. Use a level to confirm that the panels are properly aligned.
