Overview
- Terminates 4-pair, 22-26 AWG twisted pair cable
- 100% factory tested to exceed industry standards
- TG style termination eliminates need for termination tool
- Individually serialized for traceability
- Compatible with Mini-Com Modular Patch Panels and Faceplates
Specifications
Application | Unshielded |
Cable Entry | T568A/T568B |
Color | Blue |
Depth | 1.5 In. |
Material | ABS/Polycarbonate |
Model | Mini-Com |
Slot Capacity | 1 |
Standard | Exceeds component and channel requirements of ANSI/TIA-568.2-D Category 6 and ISO 11801 Class E standards at swept frequencies 1 to 250 MHz for Supporting 10GBASE-T Transmission Over Twisted Pair Cabling Systems in a 4-Connector Configuration up to 100 met |
Type | Jack Module |
Width | 0.62 In. |
Package Dimensions (L x W x H) | 13.25 IN x 10.25 IN x 4.55 IN |
Package Weight (Imperial) | 5.76 lbs |
Similar Products
You May Also Be Interested In
Frequently Asked Questions
How many mating cycles are the connectors rated for?
The connectors are rated for 2500 mating cycles, ensuring long-lasting performance.
What is the smallest diameter for Category 6A patch cords?
The smallest diameter for Category 6A patch cords is 0.185 inches (4.7mm).
What is the rated bandwidth for Category 6 cable?
Category 6 cable has a rated bandwidth of 550 MHz.
What is the maximum operating temperature for the connectors?
The connectors are rated for a maximum operating temperature of 75º C.
What is the warranty period for the Mini-Com Solution?
The Mini-Com Solution comes with a 25-year system warranty when used end-to-end.
How many times can the Mini-Com jacks be reterminated?
The Mini-Com jacks can be reterminated up to 20 times.
What is the compatibility of the NetKey jack modules?
NetKey jack modules are designed for compatibility with any keystone opening.
What safety features do the connectors have?
The connectors feature integrated arc suppression technology for enhanced safety.
What types of applications does the copper cabling support?
The copper cabling supports applications such as Power over Ethernet, wireless connectivity, intelligent lighting, security cameras, and audio/visual systems.
What is the installation method for the Mini-Com jacks?
The Mini-Com jacks feature tool-less termination, which maintains conductor twist for reliable performance.
