Overview
- High-conductivity copper lug for 4/0 AWG flexible stranded copper conductors
- Tin-plated to meet ASTM Class C corrosion resistance specifications
- Standard barrel without inspection window prevents contaminant entry
- Flared barrel entry for easier conductor insertion
- Embossed wire size identification for clear labeling
Specifications
Amperage Rating | 90 A |
Barrel Type* | Standard |
Color | Silver |
Connection Type | Screw Terminal |
Connection Type | Battery Lug |
Material | Copper |
Mounting | 15/16 In. |
Mounting Type | Battery Terminal |
Series | A4/0-12R-C |
Size | 4/0 AWG, 1/2" Stud |
Standard | cULus Listed for use in US and Canada to UL 486A-486B for power applications, meets US Military Wire Pull Out Specs |
Stud Size | 1/2 In. |
Type | Compression Lug |
Package Dimensions (L x W x H) | 8.25 IN x 4.2 IN x 4.2 IN |
Package Weight (Imperial) | 9.5 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Frequently Asked Questions
What material is the A4/0-38R-C lug made from?
The A4/0-38R-C lug is made from tin-plated copper, meeting ASTM Class C specification for corrosion resistance.
What is the A4/0-38R-C product?
The A4/0-38R-C is a Panduit Battery Compression Lug designed for heavy-duty power connector applications.
What Schleuniger tool is recommended for A4/0-38R-C?
The recommended Schleuniger tool for A4/0-38R-C is 514DA-4/0-NIT-B.350, requiring one compression.
What Greenlee tool is recommended for A4/0-38R-C?
The recommended Greenlee Hex Die for A4/0-38R-C is 10895, requiring two compressions.
What Blackfin tool is recommended for A4/0-38R-C?
The recommended Blackfin battery powered tool for A4/0-38R-C is KC22-4/0 (Purple die), requiring two compressions.
What is the pullout strength for the A4/0-38R-C lug?
The A4/0-38R-C lug has a pullout force of 450/875 lb. according to UL 486A-486B / MIL-T-7928G when using recommended tooling.
What is the required wire strip length for A4/0-38R-C?
The required wire strip length for the A4/0-38R-C lug is 15/16 inches.
What is the stud hole size for A4/0-38R-C?
The A4/0-38R-C lug has a stud hole size of 3/8 inches.
What wire size does the A4/0-38R-C lug accept?
The A4/0-38R-C lug is designed for 4/0 AWG Class K flex conductors.
What wire type is compatible with the A4/0-38R-C lug?
The A4/0-38R-C lug is designed to terminate Class K flex conductors.
How to Install the A4/0-12R-C Compression Connector
This guide provides step-by-step instructions for installing the A4/0-12R-C compression connector, ensuring a secure and reliable electrical connection.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers, Crimping tool, Multimeter
Supplies needed:
A4/0-12R-C compression connectors, 4/0 AWG copper wire, Mounting screws
- Prepare the wire
Strip the insulation from the 4/0 AWG copper wire to the length specified in the tool chart, ensuring not to nick or damage the conductor strands.
- Clean the wire
Clean the stripped end of the wire to remove any contaminants that may affect the connection.
- Insert the wire into the connector
Insert the stripped wire into the A4/0-12R-C connector until the wire stops, ensuring a snug fit.
- Crimp the connector
Using the appropriate crimping tool, place the connector in the die and crimp it. Ensure to evenly space the crimps on the barrel, starting near the tongue end and moving towards the wire end.
- Verify the connection
Use a multimeter to check the continuity of the connection to ensure it is secure and functioning correctly.
