NSI Industries
TA875-1G1
UPC: 786261976413
Contact for Pricing
Overview
- 9 selectable alarm tones: Bell, Hi-Lo, Chime, Horn, Siren, Slow Whoop
- 91-97dB output at 10 feet for high-penetration signaling
- Operates on 20-31VDC with low current draw (0.020-0.040A depending on tone)
- Compact 4.75" x 4.75" x 1.38" Dawn Mist housing for 1-gang, 2-gang, or 4" square backbox mounting
- UL listed (cULus) for indoor/outdoor use with screw terminals for #12AWG wiring
Specifications
Application | Boiler Rooms-Water Pumnping Stations-Elevators-Air Compressor Rooms |
Color | Dawn Mist |
Connection Type | Screw Terminal (#12AWG) |
Connection Type | Screw Terminals (#12AWG) |
Current Rating | 0.020 A (Bell), 0.025 A (Hi-Lo), 0.028 A (Chime), 0.026 A (Single Stroke Bell), 0.023 A (Horn), 0.023 A (3 Beeps, Pause), 0.040 A (Siren), 0.040 A (Slow Whoop) |
Current Rating | 0.020-0.040A |
Dimensions | L=5.312 - H=5.312 - D=.687 IN |
Loudness | 91-96 db At 10 Feet |
Material | Electronic Components |
Material | Steel |
Mounting | Indoor-Outdoor Box |
Mounting Type | 1-gang, 2-gang, or 4" square backboxes |
Mounting Type | 1-gang, 2-gang, or 4" square backbox |
Operating Current | .020-.040 Amps |
Operating Frequency | 60 Hz |
Operating Voltage | 24 VDC |
Series | TorkAlert |
Series | TA |
Size | 4 3/4"H x 4 3/4"W x 1 3/8"D |
Size | 4.75"H x 4.75"W x 1.375"D |
Special Features | Superior Sound Penetration For Various Room Conditions |
Standard | cULus |
Type | Multi Tine Electronic Horn |
Voltage Rating | 20-31 VDC |
Voltage Rating | 20-31VDC |
Package Dimensions (L x W x H) | 2.25 IN x 4 IN x 4 IN |
Package Dimensions (L x W x H) | 5.715 cm x 10.16 cm x 10.16 cm |
Package Weight (Imperial) | 0.500 L |
Package Weight (Metric) | 0.227 kg |
