NSI Industries L2014P - 1 Hole Long Barrel Copper Compression Lug 2/0 AWG - 1/4" Bolt Long Barrel with Peep Hole Copper Compression Lugs are produced from high conductivity copper tubing. They are tin-plated to provide corrosion low contact resistance. Marked with die index and color coded for easy reference. Listed for 35KV maximum when properly installed and to cable manufacturer instructions. Temperature rating 90 degrees C. .
NSI Industries

L2014P

UPC: 662381335623

Documents & Media
Technical BulletinInstallation Instructions

Contact for Pricing

Overview

The NSI Industries L2014P 1 Hole Long Barrel Copper Compression Lug is a high-performance electrical connector engineered for secure, low-resistance terminations in industrial and commercial wiring systems. Manufactured from high-conductivity copper tubing and tin-plated for superior corrosion resistance, this UL486A and UL467 listed lug ensures reliable performance in grounding and bonding applications up to 35KV when installed per cable manufacturer instructions. The long barrel design accommodates 2/0 AWG copper cable with a 1/4" bolt hole, providing enhanced mechanical strength and electrical continuity. The integrated peep hole (indicated by the "P" suffix) allows for visual verification of cable insertion depth, ensuring proper termination and compliance with installation standards. Color-coded and die-indexed for easy identification, the L2014P supports Class B or C building wire applications with a temperature rating of 90°C and maximum voltage of 600V. Ideal for power distribution panels, motor controls, and renewable energy systems, this compression lug delivers consistent performance in high-current environments while meeting NEC 310.15 ampacity requirements. NSI Industries, a trusted US-based manufacturer, guarantees precision-engineered components backed by rigorous testing for long-term reliability.
  • UL486A and UL467 listed for grounding/bonding applications (8 AWG–3/0 AWG)
  • Tin-plated copper construction for corrosion resistance and low contact resistance
  • 1/4" bolt hole with long barrel design for 2/0 AWG copper wire
  • Peep hole for visual verification of cable insertion (part number suffix "P")
  • 90°C temperature rating, 600V maximum, 35KV listed when properly installed

Specifications

Application
Terminate, Splice, Tap Power Connectors
Cable Size
2/0 AWG (STR)
Color
Black
Connection Type
Compression
Environmental Conditions
90 C
Finish
Tin Plated
Material
Copper
Material
Copper, Tin-Plated
Mounting
1/4 Mounting Hole IN
Number Of Holes
1
Size
2/0 AWG, 1/4" Bolt
Size
L=2.67 - W=.815 - OD=.563 - ID=.441 IN
Special Features
2/0 AWG (STR) - 1/4 Mounting Hole with Peep Hole
Standard
UL486A/B, UL467 (8 AWG -3/0 AWG)
Stud Size
1/4 IN
Type
Long Barrel - One Hole
Voltage Rating
35 kV
Voltage Rating
600 V
Warranty
1 Year
Package Dimensions (L x W x H)
2.677 IN x 0.815 IN x 0.563 IN
Package Dimensions (L x W x H)
6.7996 cm x 20.701 mm x 14.3002 mm
Package Weight (Imperial)
2.050 L
Package Weight (Metric)
0.930 kg
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.

AS-K1-H6

Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

How to Install NSI Copper Compression Connectors

Install and crimp NSI copper compression lugs or splices on concentric, compressed, or compact copper conductors. Select the correct connector size, prepare the conductor properly, and crimp using the approved tool and die set.

Estimated time: 20m

Tools needed:

Wire stripper, Wire brush, Approved crimp tool (NSI M-250, NSI M-500, NSI N12ID, or NSI N1240), Approved dies for the selected connector and conductor size

Supplies needed:

NSI copper compression lug or splice connector sized for the conductor, Copper conductor cable

  1. Select the correct connector

    Choose a lug or splice connector that matches the conductor size and application. Verify that the connector series and barrel type are approved for the cable being installed before starting.

  2. Prepare the conductor

    Carefully strip the insulation to the required length without nicking the strands. Wire brush the stripped conductor to remove oxide films, and make sure the cleaned conductor can fully insert into the connector barrel.

  3. Insert the conductor fully

    Push the stripped conductor completely into the connector barrel so the conductor fills the barrel. Confirm that the conductor is clean, fully seated, and properly aligned before crimping.

  4. Crimp with the approved tool

    Use the correct approved crimp tool and die set for the connector size. Follow the barrel markings for suggested crimp locations, and make the required number of crimps; long-barrel lugs and splices require twice the crimps shown in the table.

  5. Verify the finished connection

    Inspect the crimped connection to confirm it is secure and properly formed. Ensure the connector is fully compressed on the conductor and that no strands are loose or damaged.
