Contact for Pricing
Minimum Qty: 25
Multiplier: 25
*Contact for lower quantities*
Overview
- Solderless aluminum lug for reliable electrical connections
- Constructed from high-strength 6061T-6 aluminum alloy
- Suitable for use with #10 stud size
- Compatible with copper and aluminum conductors
- Rated for 600V (2000V max per UL486B) with a temperature rating of 90°C
Specifications
Application | Aluminum lay-in lugs are suitable for use with copper or aluminum conductors. #14 - #4 |
Connection Type | Solderless, set screw |
Material | Aluminum |
Material | 6061T-6 Aluminum Alloy |
Size | #10 stud |
Special Features | CU Wire Range: 4 thru 14 |
Standard | UL |
Type | Aluminum Lay-in Lugs |
Voltage Rating | 600V |
Package Weight (Imperial) | 0.023 L |
Package Weight (Metric) | 0.010 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Frequently Asked Questions
What conductors are compatible with the ALI-50?
The ALI-50 is suitable for use with copper or aluminum conductors ranging from #14 to #4.
What certifications does the ALI-50 have?
The ALI-50 meets NEMA Standard FB-1 and UL Standard UL-467, with UL File Number E155561.
What conductors are compatible with the ALI-50?
The ALI-50 is suitable for use with copper or aluminum conductors ranging from #14 to #4.
What certifications does the ALI-50 have?
The ALI-50 meets NEMA Standard FB-1 and UL Standard UL-467, with UL File Number E155561.
What is the material of the ALI-50?
The ALI-50 is made of aluminum with a tin electro-plated finish.
What are the dimensions of the ALI-50?
The dimensions are 10.7 inches (A), 0.38 inches (B), 0.79 inches (C), and 0.21 inches (D).
What is the material of the ALI-50?
The ALI-50 is made of aluminum with a tin electro-plated finish.
What are the dimensions of the ALI-50?
The dimensions are 10.7 inches (A), 0.38 inches (B), 0.79 inches (C), and 0.21 inches (D).
What is the stud size for the ALI-50?
The ALI-50 has a stud size of #10.
Where is the ALI-50 manufactured?
The ALI-50 is manufactured in the USA.
