NSI Industries 668-24C6S - Patch Panel 24 Port C6 S 110
NSI Industries

668-24C6S

UPC: 849160007753

Contact for Pricing

Overview

The NSI Industries PowerCat 6 24-port Angled Patch Panel (SKU: 668-24C6S) is a 1U rack-mount solution designed for Category 6 UTP cabling. This panel features patented spring-loaded shuttered DataGate RJ45 connectors with dual 568A/B color coding for straightforward identification. Its angled design enhances port access and minimizes patch cord bend radius within the rack. The panel includes an integral rear cable management tray for strain relief and tidy cable dressing. Both front and rear port numbering are provided, with individual ports designed for removable site-specific network administration using icons. This unloaded panel is compatible with standard 19" racks and includes ANSI and metric hardware kits. Manufactured in the USA.
  • 24-port Cat6 unloaded patch panel for 19" racks
  • Patented spring-loaded shuttered DataGate RJ45 connectors
  • Dual 568A/B color coding for easy identification
  • Angled design minimizes patch cord bend radius
  • Integral rear cable management tray for strain relief

Specifications

Application
Cable Installation
Connection Type
RJ45
Mounting Type
19" rack-mount
Number Of Ports
24
Series
PowerCat 6
Size
1U
Special Features
110 Punchdown type. Keeping your cables tidy. Making it easier to identify your cables. Keep your cables secure. Easier to re-configure your network. Easier to troubleshoot your network.
Type
Patch Panel
Package Dimensions (L x W x H)
20 IN x 5 IN x 2.25 IN
Package Dimensions (L x W x H)
50.8 cm x 12.7 cm x 5.715 cm
Package Weight (Imperial)
3.750 L
Package Weight (Metric)
1.701 kg
