NSI Industries 570-GI - HCF Cable Connector

NSI Industries 570-GI HCF Cable Connector

UPC: 781747757067


Documents & Media
Specification SheetVideo ClipWarrantyConflict Minerals Report

Contact for Pricing

Minimum Qty: 50

Multiplier: 50

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The NSI Industries 570-GI is a UL486A Listed HCF Cable Connector designed for reliable connections with copper cables. This green-coded compression connector is rated for 600V and 90°C, making it suitable for demanding applications. Its flared end facilitates easier cable insertion, protecting strands from chafing and breakage during movement. The tin-plated copper construction ensures corrosion resistance. With NEMA-spaced mounting holes (1¾" spacing), it offers secure installation. It is ideal for critical environments like hospital care facilities, as well as locomotive, welding, and mining cable applications.
  • UL486A Listed Wire Connector
  • Rated for 600V and 90°C
  • Flared end for easy cable insertion and strand protection
  • Tin-plated copper for corrosion resistance
  • NEMA-spaced mounting holes (1¾”)

Specifications

Angle
180 Deg
Application
Recommended cable types for use with Steel or Aluminum 14/2 (.38" 0 min) to 10/3 AWG (.61" 0 max) Health Care Facility (HCF) Armored Cable. AC/MC/MCI-A
Color
Green
Conductor Range
14/2 (.38" 0 min) to 10/3 AWG (.61" 0 max)
Connection Type
Compression
Connector Type
Color-Coded
Finish
Green Colored
Material
Zinc Die Cast
Material
Copper
Mounting Type
NEMA-spaced
Number Of Conductors
1 Cable
Series
570-GI
Size
3/8 IN
Special Features
HCF/HCFMCI-A
Standard
UL
Temperature Rating
105?°C
Trade Size
3/8 IN
Type
Connector
Voltage Rating
600V
Package Weight (Imperial)
0.069 L
Package Weight (Metric)
0.031 kg
Connector, Strap, Two Screw, Zinc Die Cast, Insulated Throat, Size K.O. 1 Inch

683-DCI2

Connector, Strap, Two Screw, Zinc Die Cast, Insulated Throat, Size K.O. 1 Inch
Connector, Screw-In, Size 3/8 Inch, Length 1.31 Inch, Width 0.92 Inch, Die Cast Zinc, Bag of 5

XC240-5

Connector, Screw-In, Size 3/8 Inch, Length 1.31 Inch, Width 0.92 Inch, Die Cast Zinc, Bag of 5
90 Degree Connector, Zinc Die Cast, Flex Size 3-1/2"

813-DC2

90 Degree Connector, Zinc Die Cast, Flex Size 3-1/2"
1" FMC/AC/MC Connector

573-DC2

1" FMC/AC/MC Connector
Connector, E-Z Lock, Steel, .406 Inch Throat Opening. Patented

AMC-50

Connector, E-Z Lock, Steel, .406 Inch Throat Opening. Patented
1/2" Steel U-Shaped Strap Connector

571-S

1/2" Steel U-Shaped Strap Connector
Connector, E-Z Lock, Steel, .560 Inch Throat Opening

AMC-52

Connector, E-Z Lock, Steel, .560 Inch Throat Opening
Mighty-Seal 1/2" PVC Jacketed MC/TECK Cable Connector

596-DC2

Mighty-Seal 1/2" PVC Jacketed MC/TECK Cable Connector

Frequently Asked Questions

What types of cables are compatible with the product?

The product is recommended for use with Steel or Aluminum 14/2 to 10/3 AWG Health Care Facility Armored Cable, AC/MC/MCI-A.

What is the material of the 570-GI connector?

The 570-GI connector is made of Zinc Die Cast material.

What certifications does the 570-GI connector have?

The connector is certified under Federal Specification A-A-50552, NEMA FB-1, and UL514B.

What is the finish of the 570-GI connector?

The finish of the 570-GI connector is green colored.

What are the dimensions of the 570-GI connector?

The dimensions are: A: 13/32 inches, B: 5/8 inches, C: 1 inch.

What is the catalog ID for the 570-GI connector?

The catalog ID for the 570-GI connector is 570-GI.

What is the trade size of the 570-GI connector?

The trade size of the 570-GI connector is 3/8 inches.

Where is the 570-GI connector manufactured?

The 570-GI connector is manufactured in the USA.

What is the UPC number for the 570-GI connector?

The UPC number for the 570-GI connector is 781747757067.

What is the standard package quantity for the 570-GI?

The standard package quantity for the 570-GI connector is 500 units.
