NSI Industries 545-DC2 - AC/MC Single Screw Strap Type Connector

NSI Industries 545-DC2 AC/MC Single Screw Strap Type Connector

UPC: 781747155450


Documents & Media
Specification SheetVideo ClipWarrantyConflict Minerals Report

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The NSI Industries 545-DC2 is a single screw strap type connector designed for AC/MC cable installations. This connector simplifies cable termination with a single screw for secure attachment, reducing installation time and labor costs. Manufactured by NSI Industries, a trusted name in electrical connectors, the 545-DC2 is ideal for industrial and commercial electrical systems where reliable cable management is critical. Its zinc die-cast construction ensures durability and resistance to corrosion, making it suitable for harsh environments. The single screw design allows for quick and easy installation without specialized tools, improving efficiency in tight spaces or high-volume installations.
  • Single screw design for quick and secure cable termination
  • Zinc die-cast construction for durability and corrosion resistance
  • Ideal for AC/MC cable installations in industrial and commercial systems
  • Reduces installation time and labor costs
  • No specialized tools required for installation

Specifications

Angle
180 Deg
Application
Recommended cable types for connecting 14/2 to 10/3 (.44" - .61" 0) AC/MC/MCIA/ HCF/HCFMCI-A Steel or Aluminum Cable to box or enclosure.
Conductor Range
14/2 to 10/3 (.44" - .61"0)
Connection Type
Screw Terminal
Connection Type
Screw
Connector Type
Single Screw, Strap Type
Finish
Ball burnish
Material
Zinc Die Cast
Material
Zinc Die-Cast
Mounting Type
Strap Type
Number Of Conductors
1 Cable
Series
545-DC2
Size
3/8 IN
Standard
UL
Trade Size
3/8 IN
Type
Connector
Package Weight (Imperial)
0.046 L
Package Weight (Metric)
0.021 kg
Connector, Screw-In, Zinc Die Cast, Flex Size 2 Inch

525-DC2

Connector, Screw-In, Zinc Die Cast, Flex Size 2 Inch
Connector, Screw-In, Size 1/2 Inch, Length 1.38 Inch, Width 0.92 Inch, Die Cast Zinc, Bag of 5

XC241-5

Connector, Screw-In, Size 1/2 Inch, Length 1.38 Inch, Width 0.92 Inch, Die Cast Zinc, Bag of 5
Connector, Screw-In, Zinc Die Cast, 105 Degree C Insulated Throat, Flex Size 1/2 Inch

520-DCI2

Connector, Screw-In, Zinc Die Cast, 105 Degree C Insulated Throat, Flex Size 1/2 Inch
Connector, Set Screw, Zinc Die Cast, Insulated Throat, Trade Size 1/2 Inch

507-DCI2

Connector, Set Screw, Zinc Die Cast, Insulated Throat, Trade Size 1/2 Inch
Connector, Set Screw, Zinc Die Cast, Insulated Throat, Trade Size 3/4 Inch

508-DCI2

Connector, Set Screw, Zinc Die Cast, Insulated Throat, Trade Size 3/4 Inch
Connector, 90 Degrees, Zinc Die Cast, Insulated Throat, Flex Size 2 Inch

810-DCI2

Connector, 90 Degrees, Zinc Die Cast, Insulated Throat, Flex Size 2 Inch
Connector, Screw-In, Zinc Die Cast, 105 Degree C Insulated Throat, Flex Size 3/8 Inch

519-DCI2

Connector, Screw-In, Zinc Die Cast, 105 Degree C Insulated Throat, Flex Size 3/8 Inch
Connector, Screw-In, Zinc Die Cast, 105 Degree C Insulated Throat, Flex Size 2 Inch

525-DCI2

Connector, Screw-In, Zinc Die Cast, 105 Degree C Insulated Throat, Flex Size 2 Inch

Frequently Asked Questions

What is the catalog ID for the 545-DC2?

The catalog ID for the 545-DC2 is 545-DC2.

What cable types are compatible with the 545-DC2?

The 545-DC2 is recommended for connecting 14/2 to 10/3 AC/MC/MCIA/HCF/HCFMCI-A Steel or Aluminum Cable.

What are the dimensions of the 545-DC2?

The dimensions are: A: 1-11/32, B: 3/8, C: 7/16, D: 15/16, E: 3/8, F: 7/16 inches.

What is the UPC number for the 545-DC2?

The UPC number for the 545-DC2 is 781747155450.

What is the material of the 545-DC2 connector?

The 545-DC2 connector is made of zinc die cast.

What is the trade size of the 545-DC2?

The trade size of the 545-DC2 is 3/8 inches.

What is the finish of the 545-DC2 connector?

The finish of the 545-DC2 connector is ball burnished and mirror smooth.

What certifications does the 545-DC2 have?

The 545-DC2 is certified under Federal Specification Number A-A-50552 and UL Standard UL-514B.

What is the standard package quantity for the 545-DC2?

The standard package quantity for the 545-DC2 is 1000 units.
