Contact for Pricing
Overview
- 1500VDC rated voltage for high-voltage DC systems
- 160A rated current for robust protection
- gBAT class for full-range overcurrent and fault current protection
- Size 2XL with direct-mount DIN-type blades for efficient integration
- UL Recognized Component (File E113357) for assured quality
Specifications
Amperage Rating | 160 A |
Application | Electrical energy storage Battery storage system Line protection between battery system and DC/DC converter or battery inverter DC grid protection |
Brand Name | Mersen |
Connection | DIN Type Blades |
Connection Material | Silver-Plated Copper |
Connection Type | DIN Type Blades |
Current Rating | 160 A |
DC Voltage Rating | 1500 V |
Mounting | Direct Mount |
Mounting Type | Direct Mount |
Series | gBat |
Size | Size 2XL |
Size | 2XL |
Size | 8.07 x 2.01 x 2.36 in |
Size | 205 x 51 x 60 mm |
Special Features | Design for DC applications Full range breaking capacity Low watt losses Minimum breaking capacity 2IN High cycling performance High interrupting rating up to 150kA |
Standard | IEC 60269-7 RoHS compliance |
Type | Battery Energy Systems |
Voltage Rating | 1500 VDC |
Package Dimensions (L x W x H) | 8.07 in x 2.01 in x 2.36 in |
Package Dimensions (L x W x H) | 205 mm x 51 mm x 60 mm |
Package Weight (Imperial) | 2.249 lb |
Package Weight (Metric) | 1.020 kg |
