Pfannenberg
46730300099
Alternate Item Number: Fuse 10X38 1A gG
Contact for Pricing
Overview
The Pfannenberg Fuse 10x38 1A gG (SKU: 46730300099) provides reliable general-purpose industrial electrical protection. This fuse features a standard 10x38mm cylindrical body, ensuring compatibility with common industrial fuse holders and blocks used in control panels and machinery. It is rated for 1A with a gG classification, suitable for operation up to 690V AC/DC and offering a high breaking capacity of 120kA. Manufactured in Germany, this fuse is part of Pfannenberg’s FR10GG69V series, designed for precise overcurrent interruption during fault conditions.
- 1A Current Rating with gG Classification
- 10x38mm Cylindrical Fuse Size
- 690V AC/DC Operating Voltage
- 120kA Breaking Capacity
- Manufactured in Germany by Pfannenberg
Specifications
Current Rating | 1A |
Current Rating | 1 A |
Series | FR10GG69V |
Size | 10x38 mm |
Size | 10X38mm |
Voltage Rating | 690 V AC/DC |
