Overview
- Rated for 600VAC/VDC and 30A maximum current
- Accepts 1-1/2" x 13/32" (10 x 38 mm) midget fuses
- Three O-rings per pole for water-resistant sealing (blue for single pole)
- Crimp terminals for #8-#12 AWG copper wire
- Breakaway version (BA) safely disconnects load during pole knockdown
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 30 A |
Application | Street lighting Parking lot lighting Traffic signaling Sports lighting Boats and marinas Humid/corrosive environments |
Brand Name | Mersen |
Class | Midget |
Connection | Crimp |
DC Voltage Rating | 600 V |
Material | Polyethylene |
Maximum Operating Temperature | 80 C |
Mounting | In-Line |
Number of poles | 1.0000 |
Number Of Poles | 1 |
Operating Temperature, Maximum | 176.00000 F |
Phase | 1 |
Size | 4.3 x 1 x 1;109.22 x 25.4 x 25.4 in;mm |
Special Features | Breakaway version quickly disconnects line side during pole knockdown in compliance with state and federal highway commission standards 3 O-rings per pole for water tight applications Colored O-rings for quick detection Single and dual poles Accepts midget or Class CC fuses Wide assortment of terminal variations High heat, impact resistant insulator Captive nut or screw for quick installations Polarized dual pole provides simultaneous disconnection Permanently installed neutral versions quickly identified by white nuts Tulip fuse clip for improved contact and low losses Environmentally friendly-no lead solder used Highly visible catalog number even with insulation boots installed Wire gauge size identified on insulation boots for quick, accurate trimming Time delay for motor starting and transformer inrush |
Standard | UL Listed Class CC Guide IZLT, File E52283 UL Recognized Component Midget Guide IZLT2, File E52283 CSA Certified Class CC and Midget Class 6225, File 32169 |
Type | UL/CSA Fuse Bases |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 4.3 in x 1 in x 1 in |
Package Dimensions (L x W x H) | 109.22 mm x 25.4 mm x 25.4 mm |
Package Weight (Imperial) | 0.100 lb |
Package Weight (Metric) | 0.045 kg |
