Contact for Pricing
Minimum Qty: 4
Multiplier: 4
*Contact for lower quantities*
Overview
- UL 98 listed 3-pole fusible switch for 600VAC systems
- 30A current rating with Class CC fuse compatibility
- 200kA interrupting capacity for robust overcurrent protection
- IP20 ingress protection rating for basic safety
- Lockout/tagout capability for compliance and safety
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 30 A |
Application | For use as main/feeder device and in conjunction with CC fuses Is rated for branch circuit protection |
Brand Name | Mersen |
Current Rating | 30 A |
Current Rating | 30A |
DC Voltage Rating | 250 V |
IP Rating | IP20 |
Maximum Operating Temperature | 75 C |
Minimum Operating Temperature | -40 C |
Mounting Type | DIN Rail |
Number Of Poles | 3 |
Poles | 3-pole |
Poles | 3 |
Series | CEP-FS |
Series | Compact Fused Disconnect |
Series | CEP |
Size | 3.65 x 2.08 x 3.4 in |
Size | 92.71 x 52.832 x 86.36 mm |
Special Features | 30A Fused disconnect UL Listed Smaller footprint compared to a traditional Class CC disconnect Accepts Class CC 30A fuses 35mm DIN rail mounted Built-in lockout/tagout feature 200kA SCCR rating 75°C CU Wire |
Standard | cULus Listed file No. E191605 UL 98 - Open type switches CSA C22.2 No.4 - enclosed and deadfront switches IEC 60529 degree of protection IP20 For motor HP ratings at full load current refer to UL table 50.1 in UL508A |
Type | UL 98 Fusible |
Voltage Rating | 600VAC |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 3.65 in x 2.08 in x 3.4 in |
Package Dimensions (L x W x H) | 92.71 mm x 52.832 mm x 86.36 mm |
Package Weight (Imperial) | 0.025 lb |
Package Weight (Metric) | 0.011 kg |
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What voltage rating does the CEP-FS30CC3 support?
The device supports 600VAC and 600VDC voltage ratings.
What is the interrupting rating of the CEP-FS30CC3?
The device has a 200kA interrupting rating, providing high fault current protection.
Does the CEP-FS30CC3 have lockout/tagout capability?
Yes, the device includes a built-in lockout/tagout feature for safety compliance.
What is the ingress protection rating of the CEP-FS30CC3?
The device has an IP20 ingress protection rating for basic protection against solid objects.
What fuse type does the CEP-FS30CC3 accept?
The device accepts UL Class CC fuses up to 30A.
Is the CEP-FS30CC3 UL 98 listed?
Yes, the device is UL 98 listed for open-type switches.
What is the pole configuration of the CEP-FS30CC3?
The device has a 3-pole configuration.
Where is the CEP-FS30CC3 manufactured?
The device is manufactured in the US by Mersen.
Is the CEP-FS30CC3 suitable for branch circuit protection?
Yes, the device is suitable for branch circuit protection when used with Class CC fuses.
Can the CEP-FS30CC3 be used as a main or feeder device?
Yes, the device is suitable for use as either a main or feeder device in panel builds.
