Mersen CEP-FS30CC2 UL 98 Fusible Switch 600VAC Class CC 30A 2-Pole
Alternate Item Number: CEP-FS30CC2
UPC: 782001500436
Documents & Media
Contact for Pricing
Minimum Qty: 6
Multiplier: 6
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- UL 98 listed fused disconnect switch
- 2-pole, 600VAC, 30A rating
- Accepts Class CC fuses for branch circuit protection
- 200kA SCCR rating
- Compact footprint with built-in lockout/tagout feature
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 30 A |
Application | For use as main/feeder device and in conjunction with CC fuses Is rated for branch circuit protection |
Brand Name | Mersen |
Current Rating | 30 A |
DC Voltage Rating | 250 V |
IP Rating | IP20 |
Maximum Operating Temperature | 75 °C |
Maximum Operating Temperature | 75 C |
Minimum Operating Temperature | -40 °C |
Minimum Operating Temperature | -40 C |
Mounting Type | DIN Rail |
Number Of Poles | 2 |
Poles | 2-Pole |
Poles | 2 |
Series | Compact Fused Disconnect |
Series | CEP |
Size | 3.65 x 1.39 x 3.4 in |
Size | 92.71 x 35.306 x 86.36 mm |
Special Features | 30A Fused disconnect UL Listed Smaller footprint compared to a traditional Class CC disconnect Accepts Class CC 30A fuses 35mm DIN rail mounted Built-in lockout/tagout feature 200kA SCCR rating 75°C CU Wire |
Standard | cULus Listed file No. E191605 UL 98 - Open type switches CSA C22.2 No.4 - enclosed and deadfront switches IEC 60529 degree of protection IP20 For motor HP ratings at full load current refer to UL table 50.1 in UL508A |
Type | UL 98 Fusible |
Voltage Rating | 600VAC |
Package Dimensions (L x W x H) | 3.65 in x 1.39 in x 3.4 in |
Package Dimensions (L x W x H) | 92.71 mm x 35.306 mm x 86.36 mm |
Package Weight (Imperial) | 0.025 lb |
Package Weight (Metric) | 0.011 kg |
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What is the amperage rating of this fused switch?
The fused switch has an amperage rating of 30A.
What type of fuses does the disconnect accept?
The disconnect accepts UL Class CC fuses up to 30A.
What is the Short Circuit Current Rating (SCCR)?
The SCCR for this device is 200kA.
What is the degree of protection for this switch?
The switch has an IEC 60529 degree of protection of IP20.
How is this switch mounted?
The switch is designed for 35mm DIN rail mounting.
Does this disconnect have a lockout/tagout feature?
Yes, it features a built-in lockout/tagout feature for added safety.
What is the recommended wire type and temperature rating?
It is rated for 75°C CU wire.
What is the required wire strip length?
The required wire strip length is 1/2 inch.
What type of screwdriver is needed for the terminals?
A Pozidriv style Philips – slot screwdriver is needed for the terminal screws.
What is the motor horsepower rating for CEP-FS30CC2?
The CEP-FS30CC2 model has a 1.5 HP rating at 240VAC, 1 Phase.
