Overview
- 1500VDC Voltage Rating for high-voltage PV systems
- 50A Current Rating for robust circuit protection
- 1XL Size with DIN Type Blades for direct mounting
- gPV type compliant with IEC 60269-6 and UL 2579 PV standards
- Designed for photovoltaic array ground fault and string fault protection
Specifications
Amperage Rating | 50 A |
Application | All photovoltaic applications Inverter DC input protection Re-combiner applications (sub combiner, array combiner, master combiner) |
Brand Name | Mersen |
Connection | DIN Type Blades |
Connection Material | Silver-Plated Copper |
DC Voltage Rating | 1500 V |
Mounting | Direct Mount |
Size | 7.56 x 1.56 x 2.07 in |
Size | 192 x 39.5 x 52.5 mm |
Special Features | Global acceptance Low fault current interrupting capability Temperature cycle withstand capability Durable construction for enhanced system longevity High efficiency with low power losses Available in 3 versions: plain blade, direct mounted, direct mounted with striker |
Standard | IEC 60269-6 RoHS compliance UL 248-19 for fuses (pending for 1XL, 2XL) (E358319, Volume 1, Section 1) UL 4248-19 for fuseholders, Photovoltaic (E362644 Volume 1) |
Sub Brand | HelioProtection® |
Type | Photovoltaic Fuses |
Package Dimensions (L x W x H) | 7.56 in x 1.56 in x 2.07 in |
Package Dimensions (L x W x H) | 192 mm x 39.5 mm x 52.5 mm |
Package Weight (Imperial) | 1.521 lb |
Package Weight (Metric) | 0.690 kg |
