Overview
- 30A current rating for 14x51mm IEC fuses (MEV55C compatible)
- Tin-plated copper box connectors for copper wires (#4 to #14 AWG)
- Rated for 750VAC and 750VDC applications
- Adder design enables modular multi-pole configurations
- UL Recognized component (File E113357)
Specifications
AC Voltage Rating | 750 V |
Amperage Rating | 30 A |
Application | All circuits up to 750 volts using semiconductor fuses for protection of small inverters, UPS systems, motor drives, etc. |
Brand Name | Mersen |
Class | IEC Cylindrical 14x51mm |
Connection | Copper Box |
Connection Type | Copper Box Connector |
Current Rating | 30A |
DC Voltage Rating | 750 V |
Material | Thermoplastic |
Material | Copper |
Maximum Operating Temperature | 80 C |
Mounting | Direct Screw Mount |
Number Of Poles | 1 |
Phase | 1 |
Poles | 1P |
Size | 3 x 0.97 x 1.37 in |
Size | 76.2 x 24.638 x 34.798 mm |
Size | 14 x 51mm |
Special Features | Thermoplastic bases DIN-rail (U710) or Screw Mount Adder block design |
Standard | UL Recognized component guide IZLT2, File E52283 CSA Certified class 6225, File 32169 |
Type | Semiconductor & Special Purpose Fuse Bases & Accessories |
Voltage Rating | 750 VAC |
Package Dimensions (L x W x H) | 3 in x 0.97 in x 1.37 in |
Package Dimensions (L x W x H) | 76.2 mm x 24.638 mm x 34.798 mm |
Package Weight (Imperial) | 0.100 lb |
Package Weight (Metric) | 0.045 kg |
Frequently Asked Questions
What fuse sizes does this block accommodate?
This block is designed for 14 x 51mm IEC cylindrical fuses.
What is the maximum voltage rating?
The fuse block is rated for 750VDC and 750VAC.
What material are the connectors made of?
The connectors are made of tin-plated copper for high conductivity.
What wire sizes are compatible with this fuse block?
The fuse block supports copper wire sizes from #4 to #14 AWG.
Can this fuse block be used in multi-pole configurations?
Yes, the adder design allows modular assembly into multi-pole configurations.
What is the recommended mounting screw size?
Recommended mounting screws are #10 (0.190" diameter).
Is this fuse block suitable for semiconductor applications?
Yes, it is designed for applications requiring robust protection, including semiconductor use.
How to Install the Mersen 70355 Fuse Block
Step-by-step guide to mounting and wiring the 70355 fuse block.
Estimated time: 15m
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws (#10 0.190" dia.), 14 x 51mm IEC fuse
- Prepare the mounting surface
Ensure the mounting surface is clean and flat. Mark and drill holes for #10 mounting screws.
- Mount the fuse block
Secure the fuse block to the surface using #10 mounting screws. Torque to 20 in-lb.
- Connect the wires
Strip wire ends to appropriate length. Insert copper wires (#4-14 AWG) into the copper box connectors and tighten securely.
- Insert the fuse
Place a 14 x 51mm IEC cylindrical fuse into the holder, ensuring proper alignment.
- Verify connections
Check all connections for tightness and proper alignment. Apply power and verify operation.
