Contact for Pricing
Overview
- 60A Class J fuse block with adder box configuration
- Supports 600VAC/600VDC applications
- Accommodates copper or aluminum conductors (#2-14 AWG)
- UL4248-listed and CSA-certified
- High-conductivity tin-plated copper fuse clips with spring-reinforced or non-spring options
- Insulators with dielectric strength exceeding 2500V
- Adder block design enables multi-pole configurations (1-, 2-, or 3-pole blocks)
Specifications
AC Voltage Rating | 600 V |
Amperage Rating | 60 A |
Brand Name | Mersen |
Class | Class J |
Connection | Box |
Connection Type | Box Connector |
Connection Type | Screw, pressure plate, box, or stud connectors |
Current Rating | 60A |
DC Voltage Rating | 600 V |
Material | Glass Filled Polycarbonate |
Material | Tin-plated copper (fuse clips), Glass-filled polycarbonate (insulator) |
Material | Glass-filled polycarbonate (GFPC) or phenolic |
Maximum Operating Temperature | 80 C |
Mounting | Direct Screw Mount |
Number Of Poles | 1 |
Phase | 1 |
Poles | 1-Pole (with adder block for multi-pole) |
Poles | Multi-pole (1-, 2-, or 3-pole blocks) |
Series | Class J |
Size | 3.9 x 1.5 x 2.2 in |
Size | 99.06 x 38.1 x 55.88 mm |
Size | #2-14 AWG |
Special Features | Class J Blocks (600V) use with AJT, A4J, HSJ |
Standard | All class J fuse blocks meet the requirements of UL4248 (formerly UL512) UL listed Guide IZLT, File E52283 CSA certified class 6225, File 32169 |
Type | UL/CSA Fuse Bases |
Voltage Rating | 600VAC/600VDC |
Voltage Rating | 600VAC 600VDC |
Voltage Rating | 600 VAC |
Package Dimensions (L x W x H) | 3.9 in x 1.5 in x 2.2 in |
Package Dimensions (L x W x H) | 99.06 mm x 38.1 mm x 55.88 mm |
Package Weight (Imperial) | 0.250 lb |
Package Weight (Metric) | 0.113 kg |
Frequently Asked Questions
What voltage ratings does the 60600J support?
The 60600J supports 600VAC and 600VDC applications.
What conductor types are compatible with the 60600J?
The 60600J accommodates stranded or solid copper or aluminum conductors with wire ranges from #2-14 AWG.
Is the 60600J UL and CSA certified?
Yes, the 60600J is UL4248-listed and CSA-certified.
What is the dielectric strength of the 60600J insulators?
The insulators have a dielectric strength exceeding 2500V.
Can the 60600J be used in multi-pole configurations?
Yes, the adder block design allows snapping onto 1-, 2-, or 3-pole blocks for multi-pole configurations.
What are the fuse clip options for the 60600J?
The 60600J features high-conductivity tin-plated copper fuse clips with spring-reinforced or non-spring options.
What is the mounting screw size for the 60600J?
Recommended mounting screws for the 60600J are 1/4" (0.250" dia).
What fuse types are recommended for use with the 60600J?
The 60600J is designed for use with Class J fuses such as AJT, A4J, and HSJ.
