Mersen 420TPMOVTS Mersen 420TPMOVTS TPMOV surge suppressor. Patented TPMOV technology prevents standard…
Alternate Item Number: 420TPMOVTS
UPC: 782001386450
Documents & Media
Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Patented TPMOV technology prevents standard MOV failure modes
- 420VAC maximum continuous operating voltage (MCOV)
- 20kA nominal discharge current rating (In) with 75kA peak surge capacity
- Visual pin indicator and normally open microswitch for remote failure indication
- Compact 0.54-inch dimension (A) for easy panel integration
- Operating temperature range: -40°C to +85°C
- Voltage protection rating (VPR): 1500V
Specifications
Application | For OEM design and build |
Frequency Rating | 50/60 HZ |
Material | PET (Polyethelene Terphthalate) |
Mounting | PCB Mount |
Operating Temperature, Maximum | 185 F |
Operating Temperature, Maximum | 85 C |
Operating Temperature, Minimum | -40 F |
Operating Temperature, Minimum | -40 C |
Size | 2.35 x 1.69 x 0.63;59.69 x 42.926 x 16.002 in;mm |
Special Features | Industry-leading TPMOV technology available in 50kA and 75kA surge capacities Consistent footprint with 25–40mm MOVs Built-in visual/remote indication optional No additional overcurrent protective device (fuses) required |
Standard | ANSI/UL 1449 5th Edition, Type 1 Component Assembly SPD, File E210793 RoHS Compliant |
Type | TPMOV (Thermally Protected MOV) |
Type of Indicators | Microswitch |
UL SPD Type | Type 1 Component Assembly |
Package Dimensions (L x W x H) | 2.35 in x 1.69 in x 0.63 in |
Package Dimensions (L x W x H) | 59.69 mm x 42.926 mm x 16.002 mm |
Package Weight (Imperial) | 0.120 lb |
Package Weight (Metric) | 0.054 kg |
