Contact for Pricing
Minimum Qty: 500
Multiplier: 500
*Contact for lower quantities*
Overview
- Patented TPMOV technology with fail-safe disconnect for enhanced reliability
- 25kA (8/20μs) impulse rating and 200kA SCCR for robust surge protection
- 320VAC MCOV and 1000V VPR compliance with ANSI/UL 1449 4th Edition Type 1 SPD
- Visual pin indicator and NO micro-switch for remote failure alerts
- UL 94 V-0 rated thermoplastic enclosure, -40°C to +85°C operation
Specifications
Application | For OEM design and build |
Connection Type | PCB-mount with short leads |
Current Rating | 25 KA |
Frequency Rating | 50/60 HZ |
Material | Metal Oxide Varistor |
Material | PET (Polyethelene Terphthalate) |
Mounting | PCB Mount |
Mounting Type | PCB-mount |
Operating Temperature, Maximum | 185 F |
Operating Temperature, Maximum | 85 C |
Operating Temperature, Minimum | -40 F |
Operating Temperature, Minimum | -40 C |
Series | 25TPMOV |
Size | 1.19 x 0.54 x 1.28;30.226 x 13.716 x 32.512 in;mm |
Size | 25mm MOV footprint |
Special Features | Industry-leading TPMOV® Technology Now available in a standard 25mm MOV footprint Upstream overcurrent protection not required Built-in end-of-life indication Type 1 CA SPD allows for use in all types of SPD applications |
Standard | ANSI/UL 1449 5th Edition, Type 1 Component Assembly SPD, File E210793 RoHS Compliant |
Type | TPMOV (Thermally Protected MOV) |
Type of Indicators | Microswitch |
UL SPD Type | Type 1 Component Assembly |
Voltage Rating | 320 VAC |
Package Dimensions (L x W x H) | 1.19 in x 0.54 in x 1.28 in |
Package Dimensions (L x W x H) | 30.226 mm x 13.716 mm x 32.512 mm |
Package Weight (Imperial) | 0.062 lb |
Package Weight (Metric) | 0.028 kg |
