Littelfuse THS422B - The THC/THS Series is a solid-state relay and timer combined into one compact, easy-to-use control. When mounted to a metal surface, the THC/THS Series may be used to directly control lamp or heater loads of up to 20A steady, 200A inrush. Its single shot function can perform dispensing and pulse shaping operations. The initiate switch can be a momentary or maintained type of switch. Time delays can be selected from 0.1 - 600 seconds in 4 ranges. The THC/THS Series is used for coin vending applications where fast initiate response is required. Operation (Single Shot): Input voltage must be applied before and during timing. Upon momentary or maintained closure of the initiate switch (leading edge triggered), the output energizes for a measured interval of time. At the end of the delay, the output de-energizes. Opening or reclosing the initiate switch during timing has no affect on the time delay. The output will energize if the initiate switch is closed when input voltage is applied. Reset: Reset occurs when the time delay is complete and theinitiate switch opens. Loss of input voltage resets the time delay and output.
Littelfuse

THS422B

Alternate Item Number: THS422B

UPC: 079458008210

Documents & Media
BrochureSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The Littelfuse THS422B solid-state relay and timer is a compact, versatile control solution designed for industrial applications requiring precise timing and reliable load management. This single-unit device combines the functionality of a relay and timer, eliminating the need for multiple components and simplifying system integration. With a robust design, the THS422B can handle steady loads of up to 20A and inrush currents of up to 200A, making it ideal for controlling lamps, heaters, and other high-power devices. The unit features a single-shot operation mode, allowing for dispensing and pulse shaping operations with time delays adjustable from 0.1 to 600 seconds across four selectable ranges. Its fast initiate response makes it particularly suitable for coin vending applications and other scenarios where quick activation is critical. The THS422B is easy to use, with an initiate switch that can be either momentary or maintained, and a reset function that ensures reliable operation. Its compact form factor and straightforward mounting to metal surfaces further enhance its versatility and ease of installation.
  • Combines solid-state relay and timer in a single compact unit
  • Controls lamp or heater loads up to 20A steady, 200A inrush
  • Adjustable time delays from 0.1 to 600 seconds in 4 ranges
  • Single-shot operation for dispensing and pulse shaping applications
  • Fast initiate response for coin vending and other time-critical applications

Specifications

Brand Name
Littelfuse
Mounting
Surface mount with one #10 (M5 x 0.8) screw Mount
Number Of Poles
Surface mount with one #10 (M5 x 0.8) screw
Operating Temperature
-20 to 60 F
Operating Temperature, Maximum
60 F
Operating Temperature, Minimum
-20 F
Special Features
10Y WARR
Standard
CE/UR/CSA
