Overview
- Adjustable flash rate: 10 to 100 operations per minute (FPM)
- DPDT electromechanical relay with 10A resistive rating at 28VDC and 120/240VAC
- 12VDC input with reverse polarity protection, 50% ON/OFF ratio
- Octal 8-pin plug-in mounting for easy installation and replacement
- Compact dimensions: 3.62 x 2.39 x 1.78 inches (91.6 x 60.7 x 45.2 mm)
FS126RC
The FA and FS Series Flashers have proven their reliability through years of use on communication towers, smoke stacks, cooling towers, tall buildings, bridges and utility towers. The highest quality components are encapsulated in a rugged plastic housing with a molded-in heat transfer plate. The flash rate, ratio, and failsafe design meet FAA regulations. Zero voltage switching can increase lamp life up to ten times. The FS155-30RF & FS165-30RF include superior RF filtering circuitry for use in high RF installations, including AM hot towers. Operation: FS Series - Flasher (OFF First), FA Series - Flashers & Aux. Modules: Upon application of input voltage, the T2 OFF time begins. At the end of the OFF time, the T1 ON time begins and the load energizes. At the end of T1, T2 begins and the load de-energizes. This cycle repeats until voltage is removed. Reset: Removing input voltage resets the output and the sequence to T2.FS127
The FA and FS Series Flashers have proven their reliability through years of use on communication towers, smoke stacks, cooling towers, tall buildings, bridges and utility towers. The highest quality components are encapsulated in a rugged plastic housing with a molded-in heat transfer plate. The flash rate, ratio, and failsafe design meet FAA regulations. Zero voltage switching can increase lamp life up to ten times. The FS155-30RF & FS165-30RF include superior RF filtering circuitry for use in high RF installations, including AM hot towers. Operation: FS Series - Flasher (OFF First), FA Series - Flashers & Aux. Modules: Upon application of input voltage, the T2 OFF time begins. At the end of the OFF time, the T1 ON time begins and the load energizes. At the end of T1, T2 begins and the load de-energizes. This cycle repeats until voltage is removed. Reset: Removing input voltage resets the output and the sequence to T2.
PCR11
The PCR Series of photo control is a combination of precision electronic circuitry, electromechanical output, and unique molded plastic housing. Designed and built to meet the demands of the most rigorous requirement of tower and obstruction lighting control, each unit is factory calibrated to meet FAA and FCC specifications. Electronic circuit, output contactor, and terminal block are all contained within front plastic housing. Edge support molded into the bottom edge of housing allows easy wiring of new and existing installations. Available with or without cast aluminum junction box. Operation: When the amount of light sensed falls below the actuation level for energization, the output relay energizes. Conversely, when the amount rises above the actuation level for de-energization, the output relay de-energizes.FS146
The FA and FS Series Flashers have proven their reliability through years of use on communication towers, smoke stacks, cooling towers, tall buildings, bridges and utility towers. The highest quality components are encapsulated in a rugged plastic housing with a molded-in heat transfer plate. The flash rate, ratio, and failsafe design meet FAA regulations. Zero voltage switching can increase lamp life up to ten times. The FS155-30RF & FS165-30RF include superior RF filtering circuitry for use in high RF installations, including AM hot towers. Operation: FS Series - Flasher (OFF First), FA Series - Flashers & Aux. Modules: Upon application of input voltage, the T2 OFF time begins. At the end of the OFF time, the T1 ON time begins and the load energizes. At the end of T1, T2 begins and the load de-energizes. This cycle repeats until voltage is removed. Reset: Removing input voltage resets the output and the sequence to T2.
FS224
The FS200 Series may be used to control inductive, incandescent, or resistive loads. Factory fixed flash rate of 45 or 90 FPM or may be ordered with a fixed custom flash rate ranging from 10 to 180 FPM. Encapsulation provides protection against shock, vibration, and humidity. Uniform performance, high inrush current capability, and low RFI, make this series ideal for general industrial applications. Operation: Upon application of input voltage, the T2 OFF time begins. At the end of the OFF time, the T1 ON time begins and the load energizes. At the end of T1, T2 begins and the load de-energizes. This cycle repeats until input voltage is removed. Reset: Removing input voltage resets the output and the sequence to T2.Frequently Asked Questions
What is the input voltage for the FS512 model?
The FS512 model has an input voltage of 12VDC.
What is the operating temperature range for the FS500 Series?
The operating temperature range for the FS500 Series is -20° to 60°C.
What is the adjustable flash rate for the FS500 Series?
The FS500 Series flash rate is adjustable from 10 to 100 operations per minute.
What is the load rating for the output contacts?
The output contacts are rated for 10A resistive at 120/240VAC and 28VDC, and 1/3 hp at 120/240VAC.
What are the dimensions of the FS500 Series?
The dimensions are H 91.6 mm (3.62”), W 60.7 mm (2.39”), D 45.2 mm (1.78”).
What type of output contacts does the FS500 Series have?
It features 10A, DPDT isolated output contacts, allowing control of AC or DC voltages.
What is the input voltage tolerance for 12VDC and 24VDC/AC models?
The input voltage tolerance for 12VDC and 24VDC/AC models is -15% to 20%.
Does the FS500 Series have reverse polarity protection?
Yes, DC units in the FS500 Series are reverse polarity protected.
How does the FS500 Series reset?
Removing input voltage resets the output and the sequence of the FS500 Series.
What is the isolation voltage between input and output?
The isolation voltage between input and output is greater than or equal to 1500V RMS.
